| BODY | COVER | ASTM A 105 | F 304 | F 304L | F 316 | F 316L | F 11 | F 22 |
| TRIMS | 13% Cr STEEL | 18% Cr 8% Ni | 18% Cr 10% Ni 2% MO + STELLITE-6 |
| MFG STD | API 602 |
| INSP & TEST STD | API 598 |
| ENDS | SOCKET WELD TO ASME B 16.11 | BUTT WELD END |
| HYD-TEST PRESSURE | BODY : 9275 Psig (652 Kg/Cm ²) |
| SEAT : 6790 Psig (477 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | COVER | ASTM A 105 | F 304 | F 304L | F 316 | F 316L | F 11 | F 22 |
| SCREEN | SS 304 | SS 316 |
| MFG STD | MARCK | 014 |
| INSP & TEST STD | MARCK | 014 |
| ENDS | SOCKET WELD TO ASME B 16.11 | BUTT WELD END |
| HYD-TEST PRESSURE | BODY : 9275 Psig (652 Kg/Cm²) |
| SEAT : 6790 Psig (477 Kg/Cm²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | BONNET | ASTM A 105 |
| TRIMS | 13 Cr |
| MFG STD | API 602 | BS 5352 |
| INSP & TEST STD | API 598 | BS 6755 |
| ENDS | SCREWED TO BSPT | NPT |
| SOCKET WELD TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY : 9000 Psig (633 Kg/Cm ²) |
| SEAT : 6600 Psig (464 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 40 MM |
| BODY | BONNET | ASTM A 105 |
| TRIMS | 13 Cr |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 6755 |
| ENDS | SCREWED TO BSP | BSPT | NPT |
| SOCKET WELD TO ASME B 16.11 | |
| HYD-TEST PRESSURE | 9000 Psig (633 Kg/Cm ²) |
| 6600 Psig (464 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 40 MM |
| BODY | BONNET | ASTM A 182 Gr F 304 | F 316 |
| TRIMS | 18 Cr 8 Ni | 18 Cr 10 Ni -2MO |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 5146 | BS 6755 |
| ENDS | SCREWED TO BSPT | NPT |
| SOCKET WELD TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY : 9000 Psig (633 Kg/Cm ²) |
| SEAT : 6600 Psig (464 Kg/Cm ²) | |
| SIZE RANGE | 20 MM TO 40 MM |
| BODY | COVER | ASTM A 105 |
| TRIMS | 13 Cr |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 6755 |
| ENDS | SCREWED TO BSPT | NPT |
| SOCKET WELD TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY : 9000 Psig (633 Kg/Cm ²) |
| SEAT : 6600 Psig (464 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 40 MM |
| BODY | COVER | ASTM A 182 Gr F 304 | F 316 |
| TRIMS | 18 Cr 8 Ni | 18 Cr 10 Ni -2MO |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 6755 |
| ENDS | SCREWED TO BSPT | NPT |
| SOCKET WELD TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY : 9000 Psig (633 Kg/Cm ²) |
| SEAT : 6600 Psig (464 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 40 MM |
| BODY | BONNET | ASTM A 182 Gr F-11 | F-22 |
| TRIMS | 13 Cr TO AISI 410 |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 6755 |
| ENDS | SCREWED TO BSPT | NPT |
| SOCKET WELD TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY : 9000 Psig (633 Kg/Cm ²) |
| SEAT : 6600 Psig (464 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 40 MM |
| BODY | BONNET | ASTM A 182 Gr F 304 | F 316 |
| TRIMS | 18 Cr 8 Ni | 18 Cr 10 Ni -2 MO |
| MFG STD | API 602 | BS 5352 |
| INSP & TEST STD | API 598 | BS 6755 |
| ENDS | SCREWED TO BSPT | NPT |
| SOCKET WELD TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY : 9000 Psig (633 Kg/Cm ²) |
| SEAT : 6600 Psig (464 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 40 MM |
| BODY | BONNET | ASTM A 182 Gr F-11 | F-22 |
| TRIMS | 13 Cr TO AISI 410 |
| MFG STD | API 602 | BS 5352 |
| INSP & TEST STD | API 598 | BS 6755 |
| ENDS | SCREWED TO BSPT | NPT |
| SOCKET WELD TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY : 9000 Psig (633 Kg/Cm ²) |
| SEAT : 6600 Psig (464 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 40 MM |
| BODY | COVER | ASTM A 182 Gr F-11 / F-22 |
| TRIMS | 12 Cr TO AISI 410 |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 6755 |
| ENDS | SCREWED TO BSPT | NPT (SOCKET WELD TO ASME B16.11 ) |
| HYD-TEST PRESSURE | BODY : 5400 Psig (379 Kg/Cm ²) |
| SEAT : 4000 Psig (281 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | BONNET | ASTM A 105 |
| TRIMS | 13 Cr |
| MFG STD | API 602 | BS 5352 |
| INSP & TEST STD | API 598 | BS 6755 |
| ENDS | SCREWED TO BSPT | NPT |
| SOCKET WELD TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY :5400 Psig (379 Kg/Cm ²) |
| SEAT :4000 Psig (281 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 40 MM |
| BODY | BONNET | ASTM A 105 |
| TRIMS | 13 Cr |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 6755 |
| ENDS | SCREWED TO BSP | BSPT | NPT |
| SOCKET WELD TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY :5400 Psig (379 Kg/Cm ²) |
| SEAT :4000 Psig (281 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 40 MM |
| BODY | BONNET | ASTM A 182 Gr F 304 | F 316 |
| TRIMS | 18 Cr 8 Ni | 18 Cr 10 Ni -2MO |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 5146 | BS 6755 |
| ENDS | SCREWED TO BSPT | NPT |
| SOCKET WELD TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY : 5400 Psig (379 Kg/Cm ²) |
| SEAT : 4000 Psig (281 Kg/Cm ²) | |
| SIZE RANGE | 20 MM TO 40 MM |
| BODY | BONNET | ASTM A 182 Gr F-11 | F-22 |
| TRIMS | 18 Cr TO AISI 410 |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 6755 |
| ENDS | SCREWED TO BSPT | NPT |
| SOCKET WELD TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY : 5400 Psig (379 Kg/Cm ²) |
| SEAT : 4000 Psig (281 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 40 MM |
| BODY | COVER | ASTM A 105 |
| TRIMS | 13 Cr |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 6755 |
| ENDS | SCREWED TO BSPT | NPT |
| SOCKET WELD TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY : 5400 Psig (379 Kg/Cm ²) |
| SEAT : 4000 Psig (281 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 40 MM |
| BODY | COVER | ASTM A 182 Gr F 304 | F 316 |
| TRIMS | 18 Cr 8 Ni | 18 Cr 10 Ni -2MO |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 6755 |
| ENDS | SCREWED TO BSPT | NPT |
| SOCKET WELD TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY : 5400 Psig (379 Kg/Cm ²) |
| SEAT : 4000 Psig (281 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 40 MM |
| BODY | COVER | ASTM A 182 Gr F -11 | F – 22 |
| TRIMS | 13 Cr TO AISI 410 |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 6755 |
| ENDS | SCREWED TO BSPT | NPT |
| SOCKET WELD TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY : 5400 Psig (379 Kg/Cm ²) |
| SEAT : 4000 Psig (281 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | BONNET | ASTM A 182 Gr F 304 | F 316 |
| TRIMS | 18 Cr 8 Ni | 18 Cr 10 Ni -2 MO |
| MFG STD | API 602 | BS 5352 |
| INSP & TEST STD | API 598 | BS 6755 |
| ENDS | SCREWED TO BSPT | NPT |
| SOCKET WELD TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY : 5400 Psig (379 Kg/Cm ²) |
| SEAT : 4000 Psig (281 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 40 MM |
| BODY | BONNET | ASTM A 182 Gr F-11 | F-22 |
| TRIMS | 13 Cr TO AISI 410 |
| MFG STD | API 602 | BS 5352 |
| INSP & TEST STD | API 598 | BS 6755 |
| ENDS | SCREWED TO BSPT | NPT |
| SOCKET WELD TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY : 5400 Psig (379 Kg/Cm ²) |
| SEAT : 4000 Psig (281 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 40 MM |
| BODY | ASTM A 105 |
| BALL | AISI 304 | AISI 316 |
| STEM | AISI 304 |
| SEAT & SEALS | PTFE |
| MFG STD | BS 5351 | BS 5159 |
| INSP & TEST STD | BS 6755 |
| PORT | FULL BORE | REDUCE BORE |
| ENDS | SCREWED TO BSP | BSPT | NPT |
| SOCKET WELD ENDS TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY : 211 Kg/cm ² |
| SEAT : 70.38 Kg/cm ² FOR 15MM TO 25MM , 51 Kg/cm ² FOR 32MM TO 50MM | |
| SIZE RANGE | 15MM TO 40MM |
| BODY | BONNET | ASTM A 105 |
| TRIMS | 13 Cr | 18 Cr |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 6755 |
| ENDS | SCREWED TO BSP | BSPT | NPT |
| SOCKET WELD TO ASME B 16.11 BUT WELD END | |
| FLANGED TO ASME B 16.5 RF | |
| HYD-TEST PRESSURE | BODY : 3000 Psig (211 Kg/Cm ²) |
| SEAT : 2000 Psig (140 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | BONNET | ASTM A 182 Gr F-11 | F-22 |
| TRIMS | 13 Cr TO AISI 410 |
| MFG STD | API 602 | BS 5352 |
| INSP & TEST STD | API 598 | BS 6755 |
| ENDS | SCREWED TO BSP | BSPT | NPT |
| SOCKET WELD TO ASME B 16.11 | |
| HYD-TEST PRESSURE | 3000 Psig (211 Kg/Cm2) |
| 2000 Psig (140 Kg/Cm2) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | BONNET | ASTM A 105 |
| TRIMS | 13 Cr |
| MFG STD | API 602 | BS 5352 |
| INSP & TEST STD | API 598 | BS 6755 |
| ENDS | SCREWED TO BSP | BSPT | NPT |
| SOCKETWELD TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY :3000 Psig (211 Kg/Cm ²) |
| SEAT :2000 Psig (140 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | BONNET | ASTM A 182 Gr F 304 | F 316 |
| TRIMS | 18 Cr 8 Ni | 18 Cr 10Ni -2MO |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 5146 | BS 6755 |
| ENDS | SCREWED TO BSP | BSPT | NPT |
| SOCKETWELD TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY : 3000 Psig (211 Kg/Cm ²) |
| SEAT : 2000 Psig (140 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | COVER | ASTM A 182 Gr F-11 | F-22 |
| TRIMS | 13 Cr TO AISI 410 |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 6755 |
| ENDS | SCREWED TO BSP | BSPT | NPT |
| SOCKET WELD TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY : 3000 Psig (211 Kg/Cm ²) |
| SEAT : 2000 Psig (140 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | BONNET | ASTM A 182 Gr F 304 | F 316 |
| TRIMS | 18 Cr 8 Ni | 18 Cr 10 Ni 2 MO |
| MFG STD | API 602 | BS 5352 |
| INSP & TEST STD | API 598 | BS 6755 |
| ENDS | SCREWED TO BSP | BSPT | NPT |
| SOCKETWELD TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY : 3000 Psig (211 Kg/Cm ²) |
| SEAT : 2000 Psig (140 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | BONNET | ASTM A 182 Gr F-11 | F-22 |
| TRIMS | 13 Cr TO AISI 410 |
| MFG STD | API 602 | BS 5352 |
| INSP & TEST STD | API 598 | BS 6755 |
| ENDS | SCREWED TO BSP | BSPT | NPT |
| SOCKET WELD TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY : 3000 Psig (211 Kg/Cm ²) |
| SEAT : 2000 Psig (140 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | COVER | ASTM A 105 |
| TRIMS | 13 Cr |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 6755 |
| ENDS | SCREWED TO BSP | BSPT | NPT |
| SOCKETWELD TO ANSI B 16.11 | |
| HYD-TEST PRESSURE | BODY : 3000 Psig (211 Kg/Cm ²) |
| SEAT : 2000 Psig (140 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | ASTM A 105 |
| BALL | AISI 304 | ASTM A 351 Gr CF8 |
| STEM | AISI 304 |
| SEAT & SEALS | PTFE |
| MFG STD | BS 5351 | BS 5159 |
| INSP & TEST STD | BS 6755 |
| PORT | FULL BORE | REDUCE BORE |
| ENDS | SCREWED TO BSP | BSPT | NPT |
| SOCKET WELD ENDS TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY : 211 Kg/cm ² |
| SEAT :70.38 Kg/cm ² FOR 15MM TO 25MM , 51 Kg/cm ² FOR 32MM TO 50MM | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | COVER | ASTM A 182 Gr F 304 | F 316 |
| TRIMS | 18 Cr 8 Ni | 18 Cr 10 Ni -2MO |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 6755 |
| ENDS | SCREWED TO BSP | BSPT | NPT |
| SOCKET WELD TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY : 3000 Psig (211 Kg/Cm ²) |
| SEAT : 2000 Psig (140 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | COVER | ASTM A 105 |
| TRIMS | 13 Cr |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| HYD-TEST PRESSURE | BODY : 1100 Psig (77 Kg/Cm ²) |
| SEAT : 800 Psig (56 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | BONNET | ASTM A 105 |
| TRIMS | 13 Cr |
| MFG STD | API 602 | BS 5352 |
| INSP & TEST STD | API 598 | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| HYD-TEST PRESSURE | BODY : 1100 Psig (77 Kg/Cm ²) |
| SEAT : 800 Psig (56 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | BONNET | ASTM A 105 |
| TRIMS | 18 Cr |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| HYD-TEST PRESSURE | BODY : 1100 Psig (77KG/CM ²) |
| SEAT : 800 Psig (56KG/CM ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | BONNET | ASTM A 182 Gr F 304 | F 316 |
| TRIMS | 18 Cr 8 Ni | 18 Cr 10 Ni – 2 MO |
| MFG STD | API 602 | BS 5352 |
| INSP & TEST STD | API 598 | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| HYD-TEST PRESSURE | BODY : 1100 Psig (77 Kg/Cm ²) |
| SEAT : 800 Psig (56 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | BONNET | ASTM A 182 Gr F 11 | F 22 |
| TRIMS | 13 Cr |
| MFG STD | API 602 | BS 5352 |
| INSP & TEST STD | API 598 | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| HYD-TEST PRESSURE | BODY : 1100 Psig (77 Kg/Cm ²) |
| SEAT : 800 Psig (56 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | BONNET | ASTM A 182 Gr F 304 | F 316 |
| TRIMS | 18 Cr 8 Ni | 18 Cr 10 Ni – 2 MO |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| HYD-TEST PRESSURE | BODY : 1100 Psig (77KG/CM ²) |
| SEAT : 800 Psig (56KG/CM ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | BONNET | ASTM A 182 Gr F 11 | F 22 |
| TRIMS | 18 Cr |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| HYD-TEST PRESSURE | BODY : 1100 Psig (77KG/CM ²) |
| SEAT : 800 Psig (56KG/CM ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | COVER | ASTM A 182 Gr F 304 | F 316 |
| TRIMS | 18 Cr 8 Ni | 18 Cr 10 Ni – 2 MO |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| HYD-TEST PRESSURE | BODY : 1100 Psig (77 Kg/Cm ²) |
| SEAT : 800 Psig (56 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | COVER | ASTM A 182 Gr F 11 | F 22 |
| TRIMS | 13 Cr |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| HYD-TEST PRESSURE | BODY : 1100 Psig (77 Kg/Cm ²) |
| SEAT : 800 Psig (56 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | ASTM A 105 |
| STEM | 13 Cr |
| MFG STD | API 602 | BS 5352 |
| INSP & TEST STD | API 598 | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF (300#) |
| HYD-TEST PRESSURE | BODY : 77 Kg/Cm² |
| SEAT : 56 Kg/Cm² | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | COVER | ASTM A 182 Gr F 304 | F 316 |
| TRIMS | 18 Cr 8 Ni | 18 Cr 10 Ni -2MO |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) |
| SEAT : 300 Psig (21 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | BONNET | ASTM A 105 |
| TRIMS | 13 Cr |
| MFG STD | API 602 | BS 5352 |
| INSP & TEST STD | API 598 | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) |
| SEAT : 300 Psig (21 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | BONNET | ASTM A 105 |
| TRIMS | 18 Cr |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) |
| SEAT : 300 Psig (21 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | BONNET | ASTM A 182 Gr F 304 | F 316 |
| TRIMS | 18 Cr 8 Ni | 18 Cr 10 Ni – 2 MO |
| MFG STD | API 602 | BS 5352 |
| INSP & TEST STD | API 598 | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) |
| SEAT : 300 Psig (21 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | BONNET | ASTM A 182 Gr F 11 | F 22 |
| TRIMS | 13 Cr |
| MFG STD | API 602 | BS 5352 |
| INSP & TEST STD | API 598 | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) |
| SEAT : 300 Psig (21 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | BONNET | ASTM A 182 Gr F 304 | F 316 |
| TRIMS | 18 Cr |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) |
| SEAT : 300 Psig (21 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | BONNET | ASTM A 182 Gr F 11 | F 22 |
| TRIMS | 18 Cr |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) |
| SEAT : 300 Psig (21 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | COVER | ASTM A 105 |
| TRIMS | 18 Cr 8 Ni | 18 Cr 10 Ni -2MO |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) |
| SEAT : 300 Psig (21 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | COVER | ASTM A 182 Gr F 11 | F 22 |
| TRIMS | 18 Cr 8 Ni | 18 Cr 10 Ni -2MO |
| MFG STD | BS 5352 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) |
| SEAT : 300 Psig (21 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | ASTM A 105 |
| STEM | 13 Cr |
| MFG STD | API 602 | BS 5352 |
| INSP & TEST STD | API 598 | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF (150#) |
| HYD-TEST PRESSURE | BODY : 30 Kg/cm² |
| SEAT : 21 Kg/cm² | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | WCB | ASTM A 351 Gr CF8 | CF8M |
| BALL | ASTM A 351 Gr CF8 | CF8M |
| STEM | AISI 304 | AISI 316 |
| SEAT & SEALS | PTFE | GFT |
| MFG STD | GENERALLY CONFORMING TO BS 5351 |
| TESTING | GENERALLY CONFORMING TO BS 6755 (PART -II) |
| PORT | “L” | “T” |
| ENDS | SCREWED TO BSP | BSPT | NPT |
| TRICLOVER | SOCKET WELD | |
| HYD-TEST PRESSURE | BODY : 15 Kg/Cm ² |
| SEAT : 10 Kg/Cm ² | |
| SIZE RANGE | 15 MM TO 100 MM |
| BODY | WCB | ASTM A 351 Gr CF8 | CF8M |
| BALL | ASTM A 351 Gr CF8 | CF8M |
| STEM | AISI 304 | AISI 316 |
| SEAT & SEALS | PTFE | GFT |
| MFG STD | GENERALLY CONFORMING TO BS 5351 |
| TESTING | GENERALLY CONFORMING TO BS 6755 (PART – II) |
| OPERATING TEMPERATURE | |
| PORT | “L” | “T” |
| ENDS | FLANGED TO BS 10 TABLE “F ” |
| FLANGED TO ASME B 16.5 RF (150#) | (300#) | |
| OPERATION | HAND LEVER | GEAR |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) |
| SEAT : 300 Psig (21 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 300 MM |
| BODY | WCB | ASTM A 351 Gr CF8 | CF8M |
| BALL | ASTM A 351 Gr CF8 | CF8M |
| STEM | AISI 304 | AISI 316 |
| SEAT & SEALS | PTFE | GTF |
| MFG STD | GENERALLY CONFORMING TO BS 5351 |
| TESTING | GENERALLY CONFORMING TO BS 6755 (PART – II) |
| OPERATING TEMPERATURE | |
| PORT | “L” | “T” | “X” |
| ENDS | FLANGED TO ASME B 16.5 RF 150# |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) |
| SEAT : 300 Psig (21 Kg/Cm ²) | |
| SIZE RANGE | 15 MM to 150 MM |
| BODY | ASTM A 351 Gr CF8 | CF8M | CF3 | CF3M |
| BALL | ASTM A 351 Gr CF8 | CF8M | CF3 | CF3M |
| STEM | AISI 304 | AISI 316 |
| SEAT & SEALS | PTFE |
| MFG STD | GENERALLY CONFORMING TO BS 5351 | ISO 17292 |
| BLOW OUT PROOF STEM | FLOATING BALL FULL BORE |
| TESTING | BS 6755 |
| ENDS | SCREWED TO BSP | BSPT | NPT | IS 554 |
| SOCKET WELD TO ASME B 16.11 | |
| SIZE RANGE | 15 MM TO 100 MM |
| BODY | ASTM A 351 Gr CF8 | CF8M | CF3 | CF3M |
| BALL | ASTM A 351 Gr CF8 | CF8M | CF3 | CF3M |
| STEM | AISI 304 | AISI 316 |
| SEAT & SEALS | PTFE |
| MFG STD | GENERALLY CONFORMING TO BS 5351 | ISO 17292 |
| BLOW OUT PROOF STEM | FLOATING BALL FULL BORE |
| TESTING | BS 6755 |
| LEVER | AISI 304 WITH PVC SLEEVE |
| ENDS | FLANGED TO ASA 150# |
| SIZE RANGE | 15 MM TO 200 MM |
| BODY | ASTM A 351 Gr CF8 | CF8M | 216 Gr WCB |
| BALL | ASTM A 351 Gr CF8 | CF8M | 216 Gr WCB |
| ENDS | SCREWED END | SOCKET WELD END |
| HYD-TEST PRESSURE | BODY : 104 Kg/Cm ² |
| SEAT : 70 Kg/Cm ² | |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | IS 210 Gr FG 200 | 220 |
| BALL | AISI 304 | ASTM A 351 Gr CF8 |
| STEM | AISI 304 |
| SEAT & SEALS | PTFE |
| MFG STD | GENERALLY CONFORMING TO BS 5159 |
| TESTING | BS 6755 | BS 5159 |
| ENDS | SCREWED TO BSP | BSPT | NPT |
| HYD-TEST PRESSURE | BODY : 225 Psig (16 Kg/Cm ²) |
| SEAT : 165 Psig (11.5 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 100 MM |
| BODY | IS 210 Gr FG 200 | 220 |
| BALL | AISI 304 | ASTM A 351 Gr CF8 |
| STEM | AISI 304 |
| SEAT & SEALS | PTFE |
| MFG STD | GENERALLY CONFORMING TO BS 5159 |
| TESTING | BS 6755 | BS 5159 |
| ENDS | FLANGED TO ASME B 16.1 FF (125#) |
| FLANGED TO BS 10 TABLE “E ” | |
| HYD-TEST PRESSURE | BODY : 225 Psig (16 Kg/Cm ²) |
| SEAT : 165 Psig (11.5 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 300 MM |
| BODY | ASTM A 216 Gr WCB | WC1 | WC6 | WC9 | LCB |
| BALL | ASTM A 304 | ASTM A 351 Gr CF8 |
| STEM | AISI 304 |
| SEAT & SEALS | PTFE |
| MFG STD | GENERALLY CONFORMING TO BS 5351 | ISO 17292 |
| TESTING | BS 6755 |
| ENDS | SCREWED TO BSP | BSPT | NPT |
| SOCKET WELD TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) |
| SEAT : 300 Psig (21 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 100 MM |
| BODY | ASTM A 216 Gr WCB | WC1 | WC6 | WC9 | LCB |
| BALL | AISI 304 | ASTM A 351 Gr CF8 |
| STEM | AISI 304 |
| SEAT & SEALS | PTFE |
| MFG STD | GENERALLY CONFORMING TO BS 5351 | ISO 17292 |
| TESTING | BS 6755 |
| ENDS | FLANGED TO BS 10 TABLE “F ” |
| FLANGED TO ASME B 16.5 RF (150#) | |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) |
| SEAT : 300 Psig (21 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 600 MM |
| BODY | ASTM A 351 Gr CF8 |
| BALL | AISI 304 | ASTM A 351 Gr CF8 |
| STEM | AISI 304 |
| SEAT & SEALS | PTFE |
| MFG STD | GENERALLY CONFORMING TO BS 5351 | ISO 17292 |
| TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 (150#/300#) |
| HYD-TEST PRESSURE | BODY :1100 Psig (77 Kg/Cm ²) (150#) |
| PNEUMATIC TEST PRESSURE : | SEAT : 100 Psig (7 Kg/Cm ²) |
| SIZE RANGE | 15 MM TO 600 MM |
| BODY | ASTM A 216 Gr WCB | WC1 | WC6 | WC9 | LCB |
| BALL | AISI 304 | ASTM A 351 Gr CF8 |
| STEM | AISI 304 |
| SEAT & SEALS | PTFE |
| MFG STD | GENERALLY CONFORMING TO BS 5351 | ISO 17292 |
| TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF (300#) |
| HYD-TEST PRESSURE | BODY : 1100 Psig (77 Kg/Cm ²) |
| PNEUMATIC TEST PRESSURE : | SEAT : 100 Psig (7 Kg /Cm ²) |
| SIZE RANGE | 15 MM TO 600 MM |
| BODY | ASTM A 351 Gr CF8 |
| BALL | AISI 304 | ASTM A 351 Gr CF8 |
| STEM | AISI 304 |
| SEAT & SEALS | PTFE |
| MFG STD | GENERALLY CONFORMING TO BS 5351 | ISO 17292 |
| TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 (150#/300#) |
| HYD-TEST PRESSURE | BODY : 1100 Psig (77 Kg/Cm ²) (300#) |
| PNEUMATIC TEST PRESSURE : | SEAT : 100 Psig (7 Kg/Cm ²) |
| SIZE RANGE | 15 MM TO 600 MM |
| BODY | ASTM A 351 Gr CF8 | CF8M | CF3 | CF3M |
| BALL | ASTM A 351 Gr CF8 | CF8M | CF3 | CF3M |
| STEM | AISI 304 | AISI 316 |
| SEAT & SEALS | PTFE |
| MFG STD | GENERALLY CONFORMING TO BS 5351 | ISO 17292 |
| BLOW OUT PROOF STEM | FLOATING BALL FULL BORE |
| TESTING | BS 6755 |
| ENDS | SCREWED TO BSP | BSPT | NPT | IS 554 |
| SOCKET WELD TO ASME B 16.11 | |
| SIZE RANGE | 8 MM TO 100 MM |
| BODY | IS 210 Gr FG 200 | 220 |
| BALL | AISI 304 | ASTM A 351 Gr CF8 |
| STEM | AISI 304 |
| SEAT & SEALS | PTFE |
| MFG STD | GENERALLY CONFORMING TO BS 5159 |
| TESTING | BS 6755 | BS 5159 |
| ENDS | SCREWED TO BSP | BSPT | NPT |
| FLANGED TO BS 10 TABLE “F ” | |
| HYD-TEST PRESSURE | BODY : 225 Psig (16 Kg/Cm ²) |
| SEAT : 165 Psig (11.5 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 100 MM |
| BODY | AISI 304 | AISI 316 |
| BALL | AISI 304 | AISI 316 | ASTM A 351 Gr CF8M |
| STEM | AISI 304 | AISI 316 |
| SEAT & SEALS | PTFE |
| MFG STD | GENERALLY CONFORMING TO BS 5351 |
| TESTING | BS 6755 |
| ENDS | SCREWED TO BSP | BSPT | NPT |
| SOCKET WELD ENDS TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) |
| SEAT : 300 Psig (21 Kg/Cm ²) | |
| SIZE RANGE | 8 MM TO 50 MM |
| BODY | AISI 304 | AISI 316 |
| BALL | AISI 304 | AISI 316 | ASTM 351 Gr CF8M |
| STEM | AISI 304 | AISI 316 |
| SEAT & SEALS | PTFE |
| MFG STD | GENERALLY CONFORMING TO BS 5351 |
| TESTING | BS 6755 |
| PORT | FULL BORE | REDUCE BORE |
| ENDS | FLANGED TO BS 10 TABLE “F ” |
| FLANGED TO ASME B 16.5 RF (150#) | |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) |
| SEAT : 300 Psig (21 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 100 MM |
| BODY | ASTM A 216 Gr WCB | ASTM A 351 Gr CF8 | CF8M | CF3 | CF3M |
| BALL | ASTM A 351 Gr CF8 | CF8M |
| MFG STD | AS PER API 6D |
| INSP & TEST STD | API 6D |
| FACE TO FACE | AS PER API 6D |
| ENDS | FLANGED END TO ASME B 16.5 RF |
| OPERATION | MANUAL | GEAR | ACTUATED |
| HYD-TEST PRESSURE | BODY : 450 Psig |
| SEAT : 315 Psig | |
| PNEUMATIC TEST PRESSURE : | SEAT : 80 Psig |
| SIZE RANGE | 40 MM TO 300 MM |
| BODY | ASTM A 216 Gr WCB | ASTM A 351 Gr CF8 | CF8M | CF3 | CF3M |
| BALL | ASTM A 351 Gr CF8 | CF8M |
| MFG STD | AS PER API 6D |
| INSP & TEST STD | API 6D |
| FACE TO FACE | AS PER API 6D |
| ENDS | FLANGED END TO ASME B 16.5 RF |
| OPERATION | MANUAL | GEAR | ACTUATED |
| HYD-TEST PRESSURE | BODY : 1125 Psig |
| SEAT : 815 Psig | |
| PNEUMATIC TEST PRESSURE : | SEAT : 80 Psig |
| SIZE RANGE | 40 MM TO 300 MM |
| BODY | BONNET | ASTM A 351 Gr CF8 | CF8M | CF3 | CF3M |
| BODY | ASTM A 216 Gr WCB | ASTM A 351 Gr CF8 | CF8M |
| MFG STD | AS PER API 6D |
| INSP & TEST STD | API 6D |
| FACE TO FACE | AS PER API 6D |
| ENDS | FLANGED END TO ASME B 16.5 RF |
| OPERATION | MANUAL | GEAR | ACTUATED |
| HYD-TEST PRESSURE | BODY : 1500 Psig |
| SEAT : 1090 Psig | |
| PNEUMATIC TEST PRESSURE : | SEAT : 80 Psig |
| SIZE RANGE | 40 MM TO 300 MM |
| BODY | ASTM A 216 Gr WCB | ASTM A 351 Gr CF8 | CF8M | CF3 | CF3M |
| BALL | ASTM A 351 Gr CF8 | CF8M |
| MFG STD | AS PER API 6D |
| INSP & TEST STD | API 6D |
| FACE TO FACE | AS PER API 6D |
| ENDS | FLANGED END TO ASME B 16.5 RF |
| OPERATION | MANUAL | GEAR | ACTUATED |
| HYD-TEST PRESSURE | BODY : 2225 Psig |
| SEAT : 1630 Psig | |
| PNEUMATIC TEST PRESSURE : | SEAT : 80 Psig |
| SIZE RANGE | 40 MM TO 300 MM |
| BODY | ASTM A 216 Gr WCB | ASTM A 351 Gr CF8 | CF8M | CF3 | CF3M |
| BALL | ASTM A 351 Gr CF8 | CF8M |
| MFG STD | AS PER API 6D |
| INSP & TEST STD | API 6D |
| FACE TO FACE | AS PER API 6D |
| ENDS | FLANGED END TO ASME B 16.5 RF | RTJ |
| OPERATION | MANUAL | GEAR | ACTUATED |
| HYD-TEST PRESSURE | BODY : 3350 Psig |
| SEAT : 2445 Psig | |
| PNEUMATIC TEST PRESSURE : | SEAT : 80 Psig |
| SIZE RANGE | 40 MM TO 300 MM |
| BODY | ASTM A 216 Gr WCB | ASTM A 351 Gr CF8 | CF8M | CF3 | CF3M |
| BALL | ASTM A 351 Gr CF8 | CF8M |
| MFG STD | AS PER API 6D |
| INSP & TEST STD | API 6D |
| FACE TO FACE | AS PER API 6D |
| ENDS | FLANGED END TO ASME B 16.5 RF | RTJ | BUTT WELD END |
| OPERATION | MANUAL | GEAR | ACTUATED |
| HYD-TEST PRESSURE | BODY : 5575 Psig |
| SEAT : 4080 Psig | |
| PNEUMATIC TEST PRESSURE : | SEAT : 80 Psig |
| SIZE RANGE | 40 MM TO 300 MM, 80 MM & ABOVE GEAR OPERATION STD |
| BODY | ASTM A 216 Gr WCB | ASTM A 351 Gr CF8 | CF8M | CF3 | CF3M |
| BALL | ASTM A 351 Gr CF8 | CF8M |
| MFG STD | AS PER API 6D |
| INSP & TEST STD | API 6D |
| FACE TO FACE | AS PER API 6D |
| ENDS | FLANGED END TO ASME B 16.5 RF | RTJ | BUTT WELD END |
| OPERATION | MANUAL | GEAR | ACTUATED |
| HYD-TEST PRESSURE | BODY : 9275 Psig |
| SEAT : 6790 Psig | |
| PNEUMATIC TEST PRESSURE : | SEAT :80 Psig |
| SIZE RANGE | 40 MM TO 300 MM 80 MM &ABOVE GEAR OPERATION STD |
| BODY | DISC | WCB | CF8 | CF8M |
| SEAT RING | EDDM |
| MFG STD | AS PER API 609 |
| INSP & TEST STD | BS EN 12266 PART-1 |
| LEAKAGE CLASS | CLASS IV AS PER 16.104 |
| RATING | 5 Kg/Cm ² |
| OPERATING TEMPERATURE | |
| ENDS | WAFER TYPE | FLANGE |
| OPERATION | GEAR OPERATED |
| HYD-TEST PRESSURE | BODY : 15 Kg/Cm ² |
| SEAT : 10 Kg/Cm ² | |
| SIZE RANGE | 80 MM TO 600 MM |
| BODY | C.I | D.I | C.S | CF8 | CF8M |
| BODY SEAT | SS 304 | SS 316 |
| DISC | C.I | D.I | C.S | CF8 | CF8M |
| MFG STD | BS EN-593 (BS 5155) | AWWA C-504 | API 609 | IS 13095 |
| INSP & TEST STD | EN 12266-1 | AWWA C-504 | API 598 |
| SHAFT | AISI 410 | AISI 304 | AISI 316 |
| BEARING BUSH | PTFE | GUN METAL |
| ENDS | DOUBLE FLANGED END TO IS 1538 | ASME B 16.5 (150#) |
| B 16.47 (SERIES-A/B) | BS 4504 | IS 6392 | |
| OPERATION | FLOW-CONTROL LEVER | GEAR | PNEUMATIC | OPERATED | ELECTRICAL | ACTUATED |
| HYD-TEST PRESSURE | BODY : 225 Psig (16 Kg/Cm ²) |
| SEAT : 165 Psig (11.5 Kg/Cm ²) | |
| SIZE RANGE | 50 MM TO 1800 MM |
| BODY | C.I | D.I | C.S | CF8 | CF8M |
| SEAT | NITRILE |
| MFG STD | API 609 |
| INSP & TEST STD | API 598 |
| SHAFT | AISI 410 | AISI 304 | AISI 316 |
| BEARING BUSH | PTFE | GUN METAL |
| ENDS | WAFER TYPE TO IS 1538 | B 16.5 (150#) |
| OPERATION | FLOW CONTROL LEAVER | GEAR | PNEUMATIC | OPERATED | ELECTRICAL | ACTUATED |
| HYD-TEST PRESSURE | BODY :225 Psig (16 Kg/Cm ²) |
| SEAT :165 Psig (11.5 Kg/Cm ²) | |
| SIZE RANGE | 65 MM TO 1800 MM |
| BODY | WCB | CF8 | CF8M |
| DISC | ASTM A 351 Gr CF8 | CF8M |
| SEAT | PTFE | GRAPHITE FILLED PTFE | GLASS FILLED PTFE |
| MFG STD | API 609 |
| INSP & TEST STD | API 598 |
| SHAFT | AISI 410 | AISI 304 | AISI 316 |
| ENDS | WAFER TYPE TO SUIT ASME B 16.5 (150#) |
| OPERATION | FLOW CONTROL LEVER | GEAR | PNEUMATIC | OPERATED | ELECTRICAL | ACTUATED |
| HYD-TEST PRESSURE | BODY : 300 Psig (21 Kg/Cm ²) |
| SEAT : 160 Psig (11 Kg/Cm ²) | |
| SIZE RANGE | 40 MM TO 1200 MM |
| BODY | WCB | CF8 | CF8M |
| DISC | ASTM A 351 Gr CF8 | CF8M |
| SEAT | PTFE | GRAPHITE FILLED PTFE | GLASS FILLED PTFE |
| MFG STD | API 609 |
| INSP & TEST STD | API 598 |
| SHAFT | AISI 410 | AISI 304 | AISI 316 |
| ENDS | WAFER TYPE TO SUIT ASME B 16.5 (150#) |
| OPERATION | FLOW CONTROL LEVER | GEAR |PNEUMATIC | OPERATED | ELECTRICAL | ACTUATED |
| HYD-TEST PRESSURE | BODY : 1100 Psig (77 Kg/Cm ²) |
| SEAT : 800 Psig (56 Kg/Cm ²) | |
| SIZE RANGE | 40 MM TO 1200 MM |
| BODY | WCB | ASTM A 351 Gr CF8 | CF8M |
| DISC | ASTM A 351 Gr CF8 | CF8M |
| SEAT | METAL TO METAL |
| INSP & TEST STD | BS 6755 | BS 5155 |
| LEAKAGE CLASS | CLASS VI AS PER 16.104 (TIGHT SHUT OFF) |
| ENDS | WAFER TYPE TO SUIT ASME B 16.5 (150#) |
| OPERATION | FLOW -CONTROL LEVER | GEAR | PNEUMATIC | OPERATED | ELECTRICAL | ACTUATED |
| HYD-TEST PRESSURE | BODY : 225 Psig (16 Kg/Cm ²) |
| SEAT : 165 Psig (11.5 Kg/Cm ²) | |
| SIZE RANGE | 50 MM TO 300 MM |
| BODY | IS 2062 Gr B (M.S.) | IS 2002 |
| BODY SEAT | SS 304 | SS 316 |
| DISC. SEAL | NITRILE | EPDM | VITON |
| DISC | IS 2062 Gr B (M.S.) | IS 2002 |
| SHAFT | AISI 410 | AISI 304 | AISI 316 |
| DISC SEAL | NITRILE | EPDM | VITON |
| LEAKAGE CLASS | CLASS VI AS PER B16.104 |
| FACE TO FACE | AS PER AWWA C-504 (ABOVE 1800 MM AS PER MFR.STD.) |
| OPERATING TEMPERATURE | |
| ENDS | AS PER AWWA C-207 CLASS B | D |
| BODY | IS 210 Gr FG 200 | 220 | ASTM A 216 Gr WCB |
| SEAT | METAL TO METAL |
| TESTING | HYDROLIC BODY : 10 Kg/Cm ² & SEAT : 5 % LEAKAGE |
| RATING | PN – 6 (MAXIMUM) |
| OPERATING TEMPERATURE | |
| ENDS | WAFER TYPE TO SUIT ASME B 16.5 (150#) |
| OPERATION | LEVER | GEAR | PNEUMATIC | OPERATED | ELECTRICAL | ACTUATED |
| SIZE RANGE | 40 MM TO 500 MM |
| BODY | ASTM A 351 Gr CF8M |
| DISC | ASTM A 351 Gr CF8M |
| SEAT | MOULDED NITRILE | EPDM | HYPLON | VITON |
| MFG STD | BS 5155 |
| INSP & TEST STD | BS 6755 | BS 5155 |
| SHAFT | AISI 410 | AISI 304 |
| ENDS | WAFER TYPE TO SUIT ASME B 16.5 |
| OPERATION | FLOW – CONTROL LEVER | GEAR | PNEUMATIC | OPERATED | ELECTRICAL | ACTUATED |
| HYD-TEST PRESSURE | BODY : 300 Psig (21 Kg/Cm ²) |
| SEAT : 220 Psig (15.5 Kg/Cm ²) | |
| SIZE RANGE | 40 MM TO 300 MM |
| BODY | IS 210 Gr FG 200 | 220 | WCB | CF8 | CF8M |
| DISC | S.G.IRON | SS 304 |
| SEAT | MOULDED NEOPRENE | NITRILE | EPDM | HYPLON | VITON |
| MFG STD | BS 5155 | IS 13095 |
| INSP & TEST STD | BS 6755 |
| SHAFT | AISI 410 | AISI 304 |
| ENDS | WAFER TYPE TO SUIT ASME B 16.5 |
| OPERATION | FLOW -CONTROL LEVER | GEAR | PNEUMATIC | OPERATED | ELECTRICAL | ACTUATED |
| HYD-TEST PRESSURE | BODY : 225 Psig (16 Kg/Cm ²) |
| SEAT : 165 Psig (11.5 Kg/Cm ²) | |
| SIZE RANGE | 40 MM TO 1500 MM |
| BODY | IS 210 Gr. FG 200 | WCB |
| DISC | S.G IRON | CF8 |
| SEAT | Nitrile |
| MFG STD | BS EN 593 | API 609 |
| INSP & TEST STD | BS EN 12266 (Part – I) | API 598 |
| SHAFT | AISI 410 | AISI 304 | AISI 316 |
| ENDS | FLANGED TO SUIT ASME B 16.5 (150#) |
| OPERATION | MANUAL | GEAR | ElECTRICAL | ACTUATED |
| HYD-TEST PRESSURE | BODY : 225 Psig (16 Kg/Cm²) |
| SEAT : 165 Psig (11.5 Kg/Cm²) |
| BODY | IS 210 Gr. FG 200 | WCB | WC1 | WC6 | WC9 |
| DISC | S.G IRON | WCB | CF8 | CF8M |
| SEAT | MOULDEN NITRILE |
| MFG STD | BS 5155 |
| INSP & TEST STD | BS 6755 | BS 5155 |
| SHAFT | AISI 410 | AISI 304 |
| ENDS | WAFER LUGGED TO SUIT |
| OPERATION | GEAR | ELECTRICAL | ACTUATED |
| HYD-TEST PRESSURE | BODY : 225 Psig (16 Kg/Cm ²) |
| SEAT : 11.5 Psig (11.5 Kg/Cm ²) |
| BODY | DISC | MS FABRICATED (IS 2062 Gr. B) |
| SEAT | METAL TO METAL |
| INSP & TEST STD | BS 6755 | BS 5155 |
| LEAKAGE CLASS | CLASS IV AS PER 16.104 |
| RATING | 5 Kg/Cm ² |
| OPERATING TEMPERATURE | |
| ENDS | DOUBLE FLANGE |
| OPERATION | LEVER | GEAR | PNEUMATIC OPERATED | ELECTRICAL ACTUATED |
| SIZE RANGE | 200 MM TO 2000 MM |
| BODY | IS 2062 | BS 2762 | BS 4360 | ASTM A 106 |
| COVER | CARBON STEEL IS 2062 |
| SCREEN | SS 304 | SS 316 |
| MFG STD | MARCK | 014 |
| INSP & TEST STD | BS 6755 PART-I | MARCK | 014 |
| ENDS | FLANGED TO ASME B16.5 RF (150#/300#/600#) |
| HYD-TEST PRESSURE | BODY : 450 Psig (32 Kg/Cm ²) |
| SIZE RANGE | 25 MM TO 1200 MM |
| BODY | IS 2062 | BS 2762 | BS 4360 | ASTM A 106 |
| COVER | CARBON STEEL IS 2062 |
| SCREEN | SS 304 | SS 316 |
| MFG STD | MARCK | 014 |
| INSP & TEST STD | BS 6755 PART-I | MARCK | 014 |
| ENDS | FLANGED TO ASME B16.5 RF (150#/300#/600#) |
| HYD-TEST PRESSURE | BODY : 450 Psig (32 Kg/Cm ²) |
| SIZE RANGE | 25 MM TO 1200 MM |
| BODY | IS 2062 | BS 2762 | BS 4360 | ASTM A 106 |
| COVER | CARBON STEEL IS 2062 |
| SCREEN | SS 304 | SS 316 |
| MFG STD | MARCK | 014 |
| INSP & TEST STD | BS 6755 PART-I | MARCK | 014 |
| ENDS | FLANGED TO ASME B 16.5 RF (150#/300#/600#) |
| HYD-TEST PRESSURE | BODY : 450 Psig (32 Kg/Cm ²) |
| SIZE RANGE | 25 MM TO 1200 MM |
| BODY | IS 210 Gr FG 200 | 220 |
| COVER | CARBON STEEL IS 2062 |
| SCREEN | SS 304 | SS 316 |
| MFG STD | MARCK | 014 |
| INSP & TEST STD | BS 6755 PART-I | MARCK | 014 |
| ENDS | FLANGED TO ASME B 16.5 RF (150#/300#/600#) |
| HYD-TEST PRESSURE | BODY :450 Psig (32 Kg/Cm ²) |
| SIZE RANGE | 25 MM TO 1200 MM |
| BODY | COVER | IS 210 Gr FG 200 | 220 |
| SCREEN | BRASS | SS 304 |
| MFG STD | MARCK | 014 |
| INSP & TEST STD | MARCK | 014 |
| ENDS | FLANGED TO BS 10 TABLE “E” |
| HYD-TEST PRESSURE | BODY : 213 Psig (15 Kg/Cm² ) |
| SIZE RANGE | 40 MM TO 350 MM |
| BODY | ASTM A 105 |
| SCREEN | SS 316 |
| MFG STD | MARCK | 024 |
| INSP & TEST STD | MARCK | 024 |
| ENDS | SCREWED | SOCKTWELD |
| HYD-TEST PRESSURE | BODY : 3000 Psig (211 Kg / Cm²) |
| SIZE RANGE | 15 MM to 50 MM |
| BODY | COVER | ASTM A 216 Gr WCB | CF8 | CF8M |
| SCREEN | SS 304 | SS 316 |
| MFG STD | MARCK | 014 |
| INSP & TEST STD | MARCK | 014 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) |
| SIZE RANGE | 15 MM TO 300 MM |
| BODY | COVER | WCB | ASTM A 351 Gr CF8 | CF8M |
| SCREEN | SS 304 | SS 316 |
| MFG STD | MARCK | 014 |
| INSP & TEST STD | MARCK | 014 |
| ENDS | SCREWED TO BSP | BSPT | NPT |
| SOCKET WELD ENDS TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm²) |
| SIZE RANGE | 15 MM TO 100 MM |
+
| BODY | COVER | ASTM A 216 Gr WCB | CF8 | CF8M |
| SCREEN | SS 304 | SS 316 |
| MFG STD | MARCK | 014 |
| INSP & TEST STD | MARCK | 014 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) |
| SIZE RANGE | 15 MM TO 300 MM |
| BODY | ASTM A 105 / SS 304 / SS 316 |
| BALL | CF8 |
| SEAT | PTFE |
| OPERATING TEMPERATURE | |
| ENDS | SCREWED / SOCKET WELD |
| BODY | WCB / CF8 / CF8M |
| BALL | CF8 / CF8M |
| SEAT | PTFE |
| DESIGN | 3 PC |
| MEDIA | AIR, WATER, OIL, GAS, STEAM |
| LEAKAGE CLASS | CLASS VI |
| OPERATING TEMPERATURE | |
| ENDS | SCREWED / SOCKET WELD |
| BALL | CF8 / CF8M |
| SEAT | PTFE |
| DESIGN | 3 PC / 2PC |
| OPERATING TEMPERATURE | |
| ENDS | FLANGED END ASA 150# |
| BODY | CF8 / CF8M |
| BALL | CF8 / CF8M |
| OPERATING TEMPERATURE | |
| PORT | L PORT / T PORT |
| ENDS | SCREWED END |
| BODY | CF8 / CF8M |
| BALL | CF8 / CF8M |
| OPERATING TEMPERATURE | |
| PORT | L PORT / T PORT |
| ENDS | FLANGED END ASA 150# |
| BODY | SGI / WCB / CF8 / CF8M |
| BALL | WCB / CF8 / CF8M |
| OPERATING TEMPERATURE | |
| ENDS | FLANGED END |
| BODY | SGI / WCB / CF8 / CF8M |
| BALL | WCB / CF8 / CF8M |
| OPERATING TEMPERATURE | |
| ENDS | FLANGED END |
| BODY | POLYPROPYLENE |
| BALL | POLYPROPYLENE |
| OPERATING TEMPERATURE | |
| ENDS | SCREWED END / FLANGED END |
| BODY | UPVC |
| BALL | UPVC |
| OPERATING TEMPERATURE | |
| ENDS | SCREWED / SOCKETWELD / FLANGED |
| BODY | WCB / CF8 / CF8M |
| BALL | CF8 / CF8M |
| SEAT | PTFE |
| DESIGN | 3 PC |
| MEDIA | AIR, WATER, OIL, GAS, STEAM |
| OPERATING TEMPERATURE | |
| ENDS | SCREWED END / SOCKETWELD END |
| BODY | WCB / CF8 / CF8M |
| BALL | CF8 / CF8M |
| SEAT | PTFE |
| DESIGN | 3 PC |
| MEDIA | AIR, WATER, OIL, GAS, STEAM |
| OPERATING TEMPERATURE | |
| ENDS | FALANGED END TO ASA 150# |
| BODY | SGI / WCB / CF8 / CF8M |
| BALL | WCB / CF8 / CF8M |
| SEAT | PFA LINED |
| DESIGN | 2 PC |
| MEDIA | ACIDIC APPLICATION |
| OPERATING TEMPERATURE | |
| ENDS | FLANGED END |
| BODY | FCS / CF8 / CF8M |
| BALL | CF8 / CF8M |
| SEAT | PTFE / GFT / CFT |
| DESIGN | 3 PC |
| MEDIA | AIR, WATER, OIL, GAS, STEAM |
| OPERATING TEMPERATURE | |
| ENDS | SCREWED END / SOCKETWELD END |
| BODY | CF8 / CF8M |
| BALL | CF8 / CF8M |
| SEAT | PTFE |
| MEDIA | AIR, WATER, OIL, GAS, STEAM |
| OPERATING TEMPERATURE | |
| ENDS | SCREWED END / SOCKETWELD END |
| BODY | SGI / WCB / CF8 / CF8M |
| BALL | WCB / CF8 / CF8M |
| SEAT | FEP |
| DESIGN | 2 PC |
| MEDIA | ACIDIC APPLICATION |
| OPERATING TEMPERATURE | |
| ENDS | FLANGED END |
| BODY | CF8 / CF8M |
| BALL | CF8 / CF8M |
| SEAT | PTFE |
| MEDIA | AIR, WATER, OIL, GAS, STEAM |
| OPERATING TEMPERATURE | |
| ENDS | FLANGED END |
| BODY | POLYPROPYLENE |
| BALL | POLYPROPYLENE |
| SEAT | PTFE |
| OPERATING TEMPERATURE | |
| ENDS | SCREWED END / FLANGED END |
| BODY | UPVC |
| BALL | UPVC |
| SEAT | PTFE |
| OPERATING TEMPERATURE | |
| ENDS | SCREWED END / FLANGED END |
| BODY | CI / CS / SS 304 / SS 316 / AS PER REQUIREMENT |
| TRIMS | 13 % Cr |
| DESIGN | BOLTED BONNET |
| MFG STD | API 600 |
| ENDS | SCREWED / FLANGED END |
| SIZE RANGE | 25MM TO 500MM |
| BODY | IS 210 GR. FG 220 (CAST IRON) / ASTM A 216 GR WCB (CAST STEEL) |
| DISC | S. G. IRON / CF8 / CF8M |
| SEAT | EPDM / SILICON / VITON |
| LEAKAGE CLASS | TIGHT SHUT OFF |
| OPERATING TEMPERATURE | |
| ENDS | WAFER ENDS ASA 150# |
| BODY | SS 304 / SS 316 |
| DISC | CF8 / CF8M |
| SEAT | EPDM / SILICON / VITON |
| LEAKAGE CLASS | TIGHT SHUT OFF |
| OPERATING TEMPERATURE | |
| ENDS | WAFER END ASA 150# |
| BODY | IS 210 GR. FG 220 (CAST IRON) / ASTM A 216 GR WCB (CAST STEEL) |
| DISC | S. G. IRON / CF8 / CF8M |
| SEAT | EPDM / SILICON / VITON |
| LEAKAGE CLASS | TIGHT SHUT OFF |
| OPERATING TEMPERATURE | |
| ENDS | DOUBLE FLANGED LONG / SHORT F TO F |
| BODY | SS 304 / SS 316 |
| DISC | CF8 / CF8M |
| SEAT | EPDM / SILICON / VITON |
| LEAKAGE CLASS | TIGHT SHUT OFF |
| OPERATING TEMPERATURE | |
| ENDS | DOUBLE FLANGED LONG / SHORT F TO F |
| BODY | IS 210 GR. FG 220 (CAST IRON) / ASTM A 216 GR WCB (CAST STEEL) |
| DISC | S. G. IRON / CF8 / CF8M |
| SEAT | EPDM / SILICON / VITON |
| LEAKAGE CLASS | TIGHT SHUT OFF |
| OPERATING TEMPERATURE | |
| ENDS | WAFER END ASA 150# |
| BODY | SS 304 / SS 316 |
| DISC | CF8 / CF8M |
| SEAT | EPDM / SILICON / VITON |
| LEAKAGE CLASS | TIGHT SHUT OFF |
| OPERATING TEMPERATURE | |
| ENDS | FULL LUG TYPE |
| BODY | WCB / SS 304 / SS 316 |
| DISC. SEAL | PTFE REPLACEABLE |
| DISC | CF8 / CF8M |
| DISC SEAL | PTFE REPLACEABLE |
| LEAKAGE CLASS | CLASS VI |
| OPERATING TEMPERATURE | |
| ENDS | WAFER END ASA 150# |
| PNEUMATIC TEST PRESSURE : | 10 KG/CM² |
| BODY | CI / WCB / CF8 / CF8M etc. |
| SEAT | METAL TO METAL/PTFE |
| DESIGN | 16 KG / CM² |
| LEAKAGE CLASS | IV |
| ENDS | WAFER / SEMI LUG / FULL LUG |
| SIZE RANGE | 50MM TO 1000MM |
| BODY | CI / CS / SS 304 / SS 316 / AS PER REQUIREMENT |
| TRIMS | 13 % Cr |
| DESIGN | BOLTED BONNET |
| MFG STD | API 600 |
| ENDS | SCREWED / FLANGED END |
| SIZE RANGE | 25MM TO 500MM |
| BODY | WCB | CF8 | CF8M |
| MEDIA | STEAM | AIR | WATER | OIL |
| MAX.SET PRESSURE | UP TO 10 Kg/Cm ² |
| OPERATING TEMPERATURE | |
| ENDS | FLANGED TO 150# |
| SIZE RANGE | 25 MM TO 100 MM 150 MM TO 250 MM (FABRICATED) |
| FLANGES | CARBON STEEL |
| GLASS | TOUGHENED BOROSIL |
| SEAT | PTFE |
| MFG STD | MARCK | 019 |
| TESTING | 100 Psig (7 Kg/Cm ²) |
| ENDS | FLANGED TO BS 10 TABLE “F ” |
| FLANGED TO ASME B 16.5 RF (150 #) | |
| SIZE RANGE | 15 MM TO 150 MM |
| FLANGES | SS 316 |
| GLASS | TOUGHENED BOROSIL |
| SEAT | PTFE |
| MFG STD | MARCK | 019 |
| TESTING | 100 Psig (7 Kg/Cm ²) |
| ENDS | FLANGED TO BS 10 TABLE “F ” |
| FLANGED TO ASME B 16.5 RF (150#) | |
| SIZE RANGE | 15 MM TO 150 MM |
| BODY | ASTM A 351 Gr CF8 | CF8M | CF3M |
| TRIMS | 18 Cr 8 Ni | 18 Cr 10 Ni 2 MO | CF 3M OR AISI 316L |
| MFG STD | MARCK | 020 |
| INSP & TEST STD | MARCK | 020 |
| ENDS | FLANGED TO BS 10 TABLE “F ” |
| FLANGED TO ASME B 16.5 RF (150#) | |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) |
| SEAT : 300 Psig (21 Kg/Cm ²) | |
| SIZE RANGE | 25 MM TO 100 MM |
| BODY | ASTM A 351 Gr CF8 | CF8M |
| BALL | ASTM A 351 Gr CF8 | CF8M |
| STEM | AISI 304 | AISI 316 |
| SEAT & SEALS | PTFE |
| MFG STD | GENERALLY CONFORMING TO BS 5351 |
| BLOW OUT PROOF STEM | FLOATING BALL FULL BORE |
| TESTING | GENERALLY CONFORMING TO BS 6755 |
| PRESS. TEMP RATING | CONFORM TO TABLE 3 OF BS 5351 |
| LEVER | AISI 304 WITH PVC SLEEVE |
| ENDS | FLANGED TO ASA 150# |
| SIZE RANGE | 50 MM x 50 MM TO 100 MM x 100 MM |
| BODY | IS 210 Gr FG 200 |
| TRIMS | AISI 304 |
| WEDGE | SS 304 PLATE |
| MFG STD | GENERALLY CONFORMING TO MSS SP 81 |
| MAX. C.W.P | 100 Psig (7 Kg/Cm²) |
| ENDS | WAFER TYPE SUITABLE FOR |
| BS 10 TABLE “D” | ASME B 16.1 (125#) | |
| SIZE RANGE | 40 MM TO 500 MM |
| BODY | ASTM A 351 Gr CF8 | CF8M |
| TRIMS | AISI 304 | AISI 316 |
| WEDGE | SS 304 | SS 316 PLATE |
| MFG STD | GENERALLY CONFORMING TO MSS SP 81 |
| INSP & TEST STD | GENERALLY CONFORMING TO MSS SP 81 |
| MAX. C.W.P | 100 Psig (7 Kg/Cm²) |
| ENDS | WAFER TYPE SUITABLE FOR |
| BS 10 TABLE “D” | ASME B 16.1 (125#) | |
| SIZE RANGE | 50 MM TO 400 MM |
| MOC | AISI 304 | AISI 316 |
| TRIMS | AISI 304 | AISI 316 |
| MFG STD | MARCK | 022 |
| TESTING | MARCK | 022 |
| HAND WHEEL | BAKELITE |
| ENDS | SCREWED TO BSP | BSPT | NPT |
| SOCKET WELD TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY : 1100 Psig (77 Kg/Cm ²) |
| SEAT : 800 Psig (56 Kg/Cm ²) | |
| SIZE RANGE | 8 MM TO 50 MM |
| BODY | POLYPROPYLENE |
| BALL & STEM | POLYPROPYLENE |
| SEAT & SEALS | PTFE |
| MFG STD | MARCK | 024 |
| TESTING | MARCK | 024 |
| ENDS | SCREWED TO BSP |
| HYD-TEST PRESSURE | BODY : 225 Psig (16 Kg/Cm ²) |
| SEAT : 165 Psig (11.5 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 100 MM |
| BODY | POLYPROPYLENE |
| BALL & STEM | POLYPROPYLENE |
| SEAT & SEALS | PTFE |
| MFG STD | MARCK | 024 |
| TESTING | MARCK | 024 |
| ENDS | FLANGED TO BS 10 TABLE “E ” |
| FLANGED TO BS 10 TABLE “F ” | |
| FLANGED TO ASME B16.5 RF (150#) | |
| HYD-TEST PRESSURE | BODY : 225 Psig (16 Kg/Cm ²) |
| SEAT : 165 Psig (11.5 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 300 MM |
| BODY | POLYPROPYLENE |
| TRIMS | CARBON STEEL |
| DIAPHRAGM | NEOPRENE RUBBER |
| ENDS | FLANGED TO BS 10 TABLE ‘D’ |
| SIZE RANGE | 15 MM TO 150MM |
| BODY | ACTACTIC POLYPROPYLENE COPOLYMER |
| BALL | POLYPROPYLENE |
| STOP RING | ACTACTIC POLYPROPYLENE |
| SEAT | PTFE |
| ENDS | SCREWED TO BSP |
| FLANGED TO BS 10 TABLE ‘D’ | |
| SIZE RANGE | 25 MM to 300 MM |
| BODY | ACTACTIC POLYPROPYLENE COPOLYMER |
| SCREEN | ACTACTIC POLYPROPYLENE |
| BALL | POLYPROPYLENE RE-INTORCED |
| STOP RING | ACTACTIC POLYPROPYLENE |
| SEAT | PTFE |
| ENDS | SCREWED TO BSP |
| FLANGED TO BS 10 TABLE ‘D’ | |
| SIZE RANGE | 25 MM to 300 MM |
| FLANGES | ACTACTIC POLYPROPYLENE COPOLYMER |
| GLASS | TOUGHENED BOROSIL GLASS |
| SEAT | PTFE |
| ENDS | FLANGED TO BS 10 TABLE “E” | “F” |
| FLANGED TO ASME B 16.5 RF (150#) | |
| SIZE RANGE | 15 MM to 300 MM |
| BODY | GGG 40 WITH FEP | PFA LINED |
| BONNET | ASTM A 216 Gr WCB |
| LINING THICKNESS | MINIMUM 3.00 MM TO 4.00 MM |
| OPERATING TEMPERATURE | |
| SPARK TEST | 15 KVDC |
| ENDS | FLANGED TO ASME B 16.5 |
| HYD-TEST PRESSURE | BODY : 10 Kg/Cm ² |
| SEAT : 10 Kg/Cm ² | |
| SIZE RANGE | 25 MM TO 200 MM |
| BODY | IS 210 Gr FG 200 | 220 | WCB | AISI 304 | AISI 316 |
| PLUG | AISI 304 | AISI 316 WITH PTFE SLEEVE |
| DIAPHRAGM | PTFE |
| ENDS | FLANGED TABLE “E” | ASA 150# |
| SIZE RANGE | 25 MM TO 150 MM |
| BODY | GGG 40 |
| DISC | CF8 + PFA | FEP LINED |
| SEAT | PTFE |
| MFG STD | BS 5155 |
| INSP & TEST STD | BS 6755 (PART- II) |
| LINING THICKNESS | MINIMUM 3.00 MM TO 4.00 MM |
| OPERATING TEMPERATURE | |
| SPARK TEST | 10 KVDC |
| ENDS | WAFER TYPE TO SUIT ASME B 16.5 (150#) |
| HYD-TEST PRESSURE | BODY : 07 Kg/Cm ² |
| SEAT : 07 Kg/Cm ² | |
| SIZE RANGE | 40 MM TO 400 MM |
| BODY | GGG 40 WITH FEP | PFA |
| BALL | ASTM A 216 216 Gr WCB + FEP | PFA LINED |
| STEM | ASTM A 216 216 Gr WCB + FEP | PFA LINED |
| LINING THICKNESS | MINIMUM 3.00 MM TO 4.00 MM |
| OPERATING TEMPERATURE | |
| SPARK TEST | 15 KVDC |
| ENDS | FLANGED TO ASME B 16.5 (150#) |
| HYD-TEST PRESSURE | BODY : 10 Kg/Cm ² |
| SEAT : 10 Kg/Cm ² | |
| SIZE RANGE | 15 MM TO 200 MM |
| BODY | GGG 40 WITH FEP | PFA |
| COVER | GGG 40 |
| PLUG | ASTM A 216 216 Gr WCB + FEP | PFA LINED |
| DIAPHRAGM | PTFE |
| LINING THICKNESS | MINIMUM 3.00 MM TO 4.00 MM |
| OPERATING TEMPERATURE | |
| SPARK TEST | 15 KVDC |
| ENDS | FLANGED TO ASME B 16.5 (150#) |
| HYD-TEST PRESSURE | BODY : 10 Kg/Cm ² |
| SEAT : 10 Kg/Cm ² | |
| SIZE RANGE | 15 MM TO 200 MM |
| BODY | COVER | ASTM A 216 Gr WCB |
| TRIMS | 13 Cr |
| MFG STD | GENERALLY CONFORMING TO BS 1873 |
| INSP & TEST STD | GENERALLY CONFORMING TO BS 6755 |
| ENDS | FLANGED TO DIN 2545 |
| HYD-TEST PRESSURE | BODY : 854 Psig (60 Kg/Cm ²) |
| SEAT : 569 Psig (40 Kg/Cm ²) | |
| SIZE RANGE | 15 MM to 250 MM |
| BODY | COVER | IS 210 Gr FG 200 | 220 |
| TRIMS | 13 Cr |
| MFG STD | GENERALLY CONFORMING TO BS 1873 |
| INSP & TEST STD | GENERALLY CONFORMING TO BS 6755 |
| ENDS | FLANGED TO DIN 2532 |
| HYD-TEST PRESSURE | BODY : 213 Psig (15 Kg/Cm ²) |
| SEAT : 142 Psig (10 Kg/Cm ²) | |
| SIZE RANGE | 15 MM to 200 MM |
| ENDS | SCREWED |
| SIZE RANGE | 15 MM TO 100 MM |
| ENDS | SCREWED |
| SIZE RANGE | 15 MM TO 100 MM |
| ENDS | SCREWED |
| SIZE RANGE | 15 MM TO 100 MM |
| BODY | ASTM A 216 Gr WCB |
| TRIMS | 13 Cr STEEL | 18 Cr 8 Ni |
| SPRING | SPRING STEEL |
| MFG STD | MARCK | 013 |
| INSP & TEST STD | MARCK | 013 |
| MAX.SET PRESSURE | 14 Kg/Cm² |
| ENDS | FLANGED TO DIN 2545 |
| HYD-TEST PRESSURE | BODY : 854 Psig (60 Kg/Cm²) |
| SIZE RANGE | 25 MM TO 150 MM |
| BODY WEDGE | ASTM A 351 Gr CF8 | CF8M |
| TRIMS | AISI 304 | AISI 316 |
| ENDS | SCREWED TO BSP |
| SOCKET WELD END TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY : 1100 Psig (77 Kg/Cm ²) |
| SEAT : 800 Psig (56 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 100 MM |
| BODY | ASTM A 216 Gr WCB |
| TRIMS | 13 Cr STEEL | 18 Cr 8 Ni |
| SPRING | SPRING STEEL |
| MFG STD | MARCK | 013 |
| INSP & TEST STD | MARCK | 013 |
| MAX.SET PRESSURE | 14 Kg/Cm² |
| ENDS | FLANGED TO DIN 2545 |
| HYD-TEST PRESSURE | BODY : 854 Psig (60 Kg/Cm²) |
| SIZE RANGE | 25 MM TO 150 MM |
| BODY | ASTM A 216 Gr WCB |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| SPRING | SPRING STEEL | SPRING WIRE |
| MFG STD | GENERALLY CONFORMING TO API 526 |
| INSP & TEST STD | ASME PTC 25-3 | API 527 |
| MAX.SET PRESSURE | 32 Kg/Cm² (460 Psig) AT 260°C |
| ENDS | FLANGED TO DIN 2545 |
| FLANGED TO BS 10 TABLE “H” | |
| SIZE RANGE | 25 MM TO 200 MM |
| BODY | ASTM A 216 Gr WCB |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| SPRING | SPRING STEEL | SPRING WIRE |
| MFG STD | GENERALLY CONFORMING TO API 526 & IBR |
| INSP & TEST STD | ASME PTC 25-3 | API 527 |
| MAX.SET PRESSURE | (STEAM) 17.5 Kg/Cm² (250 Psig) AT 427°C |
| ENDS | INLET : FLANGED TO BS 10 TABLE “H” |
| OUTLET : FLANGED TO BS 10 TABLE “F” | |
| HYD-TEST PRESSURE | BODY : 500 Psig (35 Kg/Cm²) |
| SIZE RANGE | 25 MM TO 100 MM |
| BODY | ASTM A 216 Gr WCB | ASTM A 351 GR. CF8 |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| SPRING | SPRING STEEL | SPRING WIRE |
| SEAT & SEALS | METAL TO METAL |
| MFG STD | GENERALLY CONFORMING TO API 526 & IBR |
| INSP & TEST STD | GENERALLY CONFORMING TO API 527 |
| MEDIA | WATER / STEAM / OIL |
| MAX.SET PRESSURE | 0.5 TO 6 KG/CM² FOR 150# 6 TO 25 KG/CM² FOR 150# 25 TO 45 KG/CM² FOR 300# |
| ENDS | FLANGED END TO 150# / 300# |
| SCREWED END | |
| SIZE RANGE | 15 MM TO 300 MM |
| BODY | COVER | ASTM A 216 Gr WCB |
| TRIMS | 13 Cr Steel (SS 410) |
| MAX. INLET PRESSURE | 10.54 Kg/Cm ² AT 220 °C |
| MFG STD | IS 12268 |
| INSP & TEST STD | IS 12268 |
| ENDS | SCREWED TO BSP | BSPT | NPT (FEMALE) |
| SOCKET WELD END TO ASME B 16.11 | |
| HYD-TEST PRESSURE | BODY : 455 Psig (32 Kg/Cm ²) |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | CAST IRON (IS 210 Gr FG 200) |
| COVER | CAST IRON (IS 210 Gr FG 200) |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MAX. INLET PRESSURE | 10.54 Kg/Cm ² AT 220 °C |
| MFG STD | IS 12268 |
| INSP & TEST STD | IS 12268 |
| ENDS | SCREWED TO BSP |
| HYD-TEST PRESSURE | BODY : 213 Psig (15 Kg/Cm ²) |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | CAST IRON (IS 210 Gr FG 200) |
| COVER | CAST IRON (IS 210 Gr FG 200) |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MAX. INLET PRESSURE | 10.54 Kg/Cm ² AT 220 °C |
| MFG STD | IS 12268 |
| INSP & TEST STD | IS 12268 |
| ENDS | SCREWED TO BSP |
| HYD-TEST PRESSURE | BODY : 300 Psig (21 Kg/Cm ²) |
| SIZE RANGE | 15 MM TO 50 MM |
| BODY | ASTM A 351 Gr CF8 | CA15 |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MAX. INLET PRESSURE | 32 Kg/Cm ² AT 425 °C |
| MINIMUM PRESSURE | 0.25 Kg/Cm ² |
| MAX. BACK PRESSURE | SHOULD NOT EXCEED 80% OF THE INLET PRESSURE |
| ENDS | SCREWED TO BSP |
| HYD-TEST PRESSURE | 911 Psig (64 Kg/Cm ²) |
| SIZE RANGE | 15 MM TO 25 MM |
| BODY | ASTM A 216 Gr WCB |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| DIAPHRAGM | RE-INFORCED RUBBER |
| MFG STD | GENERALLY CONFORMING TO IS 10189 (PART 1) |
| INSP & TEST STD | GENERALLY CONFORMING TO IS 10189 (PART I) | ASME B 16.104 | FCI 70-2 |
| ENDS | FLANGED TO ASME B 16.5 RF (150# | 300#) |
| FLANGED TO DIN 2543 | |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) FOR 150# | TABLE “F ” | 1100 Psig (79 Kg/Cm ²) FOR 300# |
| SEAT : 32 Kg/Cm ² FOR PN16 | |
| SIZE RANGE | 15 MM TO 300 MM |
| BODY | ASTM A 216 Gr WCB |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| DIAPHRAGM | RE-INFORCED RUBBER |
| MFG STD | GENERALLY CONFORMING TO IS 10189 (PART I) |
| INSP & TEST STD | GENERALLY CONFORMING TO IS 10189 (PART I) | ASME B 16.104 | FCI 70-2 |
| ENDS | FLANGED TO ASME B 16.5 RF (150# | 300#) |
| FLANGED TO DIN 2543 | |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) FOR 150# & TABLE “F ” | 1100 Psig (79 Kg/Cm ²) FOR 300# | 32 Kg/Cm ² FOR PN16 |
| PNEUMATIC TEST PRESSURE : | 150# | 300# | PN 16 |
| SIZE RANGE | 15 MM TO 300 MM |
| BODY | ASTM A 216 Gr WCB |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| DIAPHRAGM | RE-INFORCED RUBBER |
| MFG STD | GENERALLY CONFORMING TO IS 10189 (PART 1) |
| INSP & TEST STD | GENERALLY CONFORMING TO IS 10189 (PART I) | ANSI B 16.104 | FCI 70-2 |
| ENDS | FLANGED TO ASME B 16.5 RF (150#/300#) |
| FLANGED TO DIN 2543 | |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) FOR 150# | TABLE “F ” |
| BODY : 1100 Psig (79 Kg/Cm ²) FOR 300# | 32 Kg/Cm ² FOR PN16 | |
| PNEUMATIC TEST PRESSURE : | 150# | 300# | PN 16 |
| SIZE RANGE | 15 MM TO 300 MM |
| BODY | ASTM A 216 Gr WCB |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | GENERALLY CONFORMING TO IS 10189 (PART I) |
| TESTING | GENERALLY CONFORMING TO IS 10189 (PART I) | ANSI B 16.104 | FCI 70-2 |
| ENDS | FLANGED TO ASME B 16.5 RF (150#/300#) |
| FLANGED TO DIN 2543 | |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) FOR 150# | TABLE “F ” |
| BODY :1100 Psig (79 Kg/Cm ²) FOR 300# | 32 Kg/Cm ² FOR PN16 | |
| PNEUMATIC TEST PRESSURE : | 150# | 300# | PN 16 |
| SIZE RANGE | 15 MM TO 300 MM |
| BODY | ASTM A 216 Gr WCB |
| TRIMS | 13 Cr |18 Cr 8 Ni |
| MFG STD | IS 10189 (PART I) |
| TESTING | IS 10189 (PART I) ASME B 16.104 | FCI 70-2 |
| ENDS | FLANGED TO ASME B 16.5 RF (150#/300#) |
| FLANGED TO DIN 2543 | |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) FOR 150#/TABLE “F ” |
| BODY : 1100 Psig (79 Kg/Cm ²) FOR 300#, 32 Kg/Cm ² FOR PN16 | |
| PNEUMATIC TEST PRESSURE : | 150# | 300# | PN 16 |
| SIZE RANGE | 15 MM TO 300 MM |
| BODY | ASTM A 216 Gr WCB |
| PLUG | ASTM A 216 Gr WCB |
| MFG STD | GENERALLY CONFORMING TO MSS SP 78 | BS 5158 |
| INSP & TEST STD | GENERALLY CONFORMING TO MSS SP 78 | BS 6755 |
| MAX. C.W.P | 150 Psig (10.54 Kg/Cm ²) |
| ENDS | FLANGED TO ASME B 16.5 RF (150#) |
| HYD-TEST PRESSURE | BODY :225 Psig (16 Kg/Cm ²) |
| SEAT :165 Psig (11.5 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 350 MM FLANGED END |
| BODY | CI | DI | WCB |
| DIAPHRAGM | NEOPRENE RUBBER | EPDM | PTFE |
| MFG STD | BS 5156 |
| INSP & TEST STD | BS 6755 |
| LINING THICKNESS | EBONITE RUBBER | NEOPRENE | EPDM | EBONITE |
| ENDS | FLANGED TO BS 10 TABLE “D ” & “E” I ASME B16.5 |
| CLASS 150 | PN10 | SCREWED END | |
| HYD-TEST PRESSURE | BODY : 213 Psig (15 Kg/Cm ²) |
| SEAT : 142 Psig (10 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 300 MM |
| BODY | ASTM A 351 Gr CF8 | CF8M | CF3 | CF3M |
| BONNET | IS 210 Gr FG 200 |
| DIAPHRAGM | NEOPRENE | PTFE | NBR | EPDM | PTFE |
| ENDS | SCREWED | TRI-CLOVER (TC) |
| SIZE RANGE | 15 MM TO 80 MM |
| BODY | IS 210 Gr FG 200 CI | DI | WCB |
| DIAPHRAGM | NEOPRENE RUBBER | EPDM | PTFE |
| MFG STD | BS 5156 |
| INSP & TEST STD | BS 6755 |
| LINING THICKNESS | EBONITE RUBBER | NEOPRENE | EPDM | EBONITE |
| ENDS | FLANGED TO BS 10 TABLE “ D ” & ” E ” I ASME B16.5 |
| CLASS 150 | PN10 | SCREWED END | |
| HYD-TEST PRESSURE | BODY : 213 Psig (15 Kg/Cm ²) |
| SEAT : 142 Psig (10 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 300 MM |
| BODY | IS 210 Gr FG 200 |
| BALL | NEOPRENE COATED TIMBER |
| MFG STD | MARCK | 016 |
| TESTING | MARCK | 016 |
| MAX. C.W.P | 100 Psig (7 Kg/Cm²) |
| ENDS | SCREWED TO BSP |
| HYD-TEST PRESSURE | BODY : 225 Psig (16 Kg/Cm²) |
| SIZE RANGE | 15 MM TO 100 MM |
| BODY | IS 210 Gr FG 200 |
| BALL | NEOPRENE COATED TIMBER |
| MFG STD | MARCK | 016 |
| TESTING | MARCK | 016 |
| MAX. C.W.P | 100 Psig (7 Kg/Cm²) |
| ENDS | FLANGED TO BS 10 TABLE “D” |
| FLANGED TO ASME B 16.1 FF (125#) | |
| HYD-TEST PRESSURE | BODY : 225 Psig (16 Kg/Cm²) |
| SIZE RANGE | 25 MM TO 300 MM |
| BODY | IS 210 Gr FG 200 |
| TRIMS | AISI 410 |
| BALL | NEOPRENE COATED TIMBER |
| MFG STD | MARCK | 016 |
| TESTING | MARCK | 016 |
| MAX. C.W.P | 100 Psig (7 Kg/Cm²) |
| ENDS | FLANGED TO BS 10 TABLE “D” |
| FLANGED TO ASME B 16.1 FF (125#) | |
| HYD-TEST PRESSURE | BODY : 225 Psig (16 Kg/Cm²) |
| SEAT : 165 Psig (11.5 Kg/Cm²) | |
| SIZE RANGE | 25 MM TO 250 MM |
| BODY | IS 210 Gr FG 200 |
| BALL | NEOPRENE COATED TIMBER |
| MFG STD | MARCK | 016 |
| TESTING | MARCK | 016 |
| MAX. C.W.P | 100 Psig (7 Kg/Cm²) |
| ENDS | FLANGED TO BS 10 TABLE “D” |
| FLANGED TO ASME B 16.1 FF (125#) | |
| HYD-TEST PRESSURE | BODY : 225 Psig (16 Kg/Cm²) |
| SIZE RANGE | 25 MM TO 200 MM |
| BODY | IS 210 Gr FG 200 |
| TRIMS | STAINLESS STEEL | GUN METAL |
| BALL | NEOPRENE COATED TIMBER |
| MFG STD | MARCK | 016 |
| TESTING | MARCK | 016 |
| MAX. C.W.P | 100 Psig (7 Kg/Cm²) |
| ENDS | FLANGED TO BS 10 TABLE “D” |
| FLANDED TO ASME B 16.1 FF (125#) | |
| HYD-TEST PRESSURE | BODY : 225 Psig (16 Kg/Cm²) |
| SIZE RANGE | 40 MM to 200 MM |
| BODY COVER COWL | CAST IRON, DUCTILE IRON, CAST IRON |
| SEAT RING | NITRILE | EPDM |
| SMALL ORIFICE NIPPLE | BRONZE (STANDARD) | STAINLESS STEEL |
| SMALL ORIFICE BALL | STAINLESS STEEL (STANDARD) | RUBBER LINED SEASONED TIMBER |
| MFG STD | IS 14845 | MARCK 016 |
| MAX. C.W.P | PN 10 | PN 1.6 |
| ENDS | FLANGED END TO IS 1538 | ASME B 16.5 |
| HYD-TEST PRESSURE | BODY : 225 PSIG (15 KG/CM²) |
| SEAT : 165 PSIG (11.5 KG/CM²) | |
| SIZE RANGE | 50 MM TO 200 MM |
| BODY | BONNET | ASTM A 216 Gr. WCB | WC1 | WC6 | WC9 | LCB ASTM A 351 Gr. CF8 | CF8M | CF3 | CF3M |
| TRIMS | 13 Cr. | 18 Cr. Ni |
| MFG STD | API 6D |
| INSP & TEST STD | API 6D |
| CLASS | 150# | 300# | 400# | 600# | 900# | 1500# | 2500# |
| ENDS | FLANGED TO ASME B 16.5 RF | RTJ |
| BUTTWELD TO ASME B 16.25 | |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| FIRE SAFE | API 6FA |
| SIZE RANGE | 2″ TO 24″ |
| BODY | COVER | ASTM A 216 Gr. WCB | WC1 | WC6 | WC9 | LCB ASTM A 351 Gr. CF8 | CF8M | CF3 | CF3M |
| TRIMS | 13 Cr. | 18 Cr. 8 Ni |
| MFG STD | API 6D |
| INSP & TEST STD | API 6D |
| CLASS | 150# | 300# | 400# | 600# | 900# | 1500# | 2500# |
| ENDS | FLANGED TO ASME B 16.5 RF | RTJ |
| BUTTWELD TO ASME B 16.25 | |
| FIRE SAFE | API 6FD |
| SIZE RANGE | 2″ TO 24″ |
| BODY | ASTM A 216 Gr. WCB | WC1 | WC6 | WC9 | LCB ASTM A 361 Gr. CF8 | CF8M | CF3 | CF3M |
| BALL | ASTM A 351 Gr CF8 | CF8M |
| SEAT | PTFE | NYLON | PEEK |
| DESIGN | 2 PIECE | 3 PIECE |
| MFG STD | API 6D |
| INSP & TEST STD | API 6D |
| CLASS | 150# | 300# | 400# | 600# | 900# | 1500# | 2500# |
| ENDS | FLANGED TO ASME B 16.5 RF | RTJ |
| BUTTWELD TO ASME B 16.25 | |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| FIRE SAFE | API 607 |
| SIZE RANGE | 2″ TO 28″ |
| BODY | ASTM A 351 Gr CF8 | CF8M | CF3 | CF3M |
| PIN | 18 Cr 8 Ni TO AISI 304 |
| RINGS | MOULDED NEOPRENE | NITRILE | PTFE |
| MFG STD | GENERALLY CONFORMING TO API 6D |
| TEST STD | GENERALLY CONFORMING TO API 6D |
| ENDS | WAFER TYPE |
| HYD-TEST PRESSURE | BODY : 225 Psig (16 Kg/Cm ²) |
| SEAT : 165 Psig (11.5 Kg/Cm ²) | |
| SIZE RANGE | 25 MM TO 600 MM |
| BODY | EN 8 |
| PIN | 13 Cr TO AISI 410 | 18 Cr 8 Ni TO AISI 304 | 316 |
| RINGS | MOULDED NEOPRENE | NITRILE | PTFE |
| MFG STD | GENERALLY CONFORMING TO API 6D |
| TEST STD | GENERALLY CONFORMING TO API 6D |
| ENDS | WAFER TYPE |
| HYD-TEST PRESSURE | BODY : 225 Psig (16 Kg/Cm ²) |
| SEAT : 165 Psig (11.5 Kg/Cm ²) | |
| SIZE RANGE | 25 MM TO 600 MM |
| BODY | ASTM A 361 Gr CF8 | CF8M | CF3 | CF3M |
| DISC | SS 304 | SS 316 |
| SPRING | STAINLESS STEEL |
| SPRING RETAINER | AISI 304 | AISI 316 |
| SEAT | METAL TO METAL | EPDM | NiTRILE | PTFE |
| INSP & TEST STD | API 598 |
| ENDS | WAFER TYPE FOR 15 MM TO 200 MM |
| SCREWED END FOR 15 MM TO 100 MM | |
| HYD-TEST PRESSURE | BODY : 854 Psig (60 Kg/Cm ²) |
| SEAT : 569 Psig (40 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 200 MM |
| BODY | ASTM A 216 Gr WCB | WC1 | WC6 | WC9 | LCB |
| CLOSURE PLATE (DISC) | SS 304 | SS 316 |
| HING PIN | AISI 304 | AISI 316 |
| STOP PIN | AISI 304 | AISI 316 |
| SPRING | STAINLESS STEEL |
| SEAT | EPDM |
| MFG STD | GENERALLY CONFORMING TO API 6D | API 594 |
| INSP & TEST STD | GENERALLY CONFORMING TO API 6D | API 598 |
| ENDS | WAFER TYPE TO SUIT ANSIB 16.5 (150#) |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) |
| SEAT : 300 Psig (21 Kg/Cm ²) | |
| SIZE RANGE | 50 MM TO 600 MM |
| BODY | ASTM A 216 Gr WCB | WC1 | WC6 | WC9 | LCB |
| CLOSURE PLATE (DISC) | SS 304 | SS 316 |
| HING PIN | AISI 304 | AISI 316 |
| STOP PIN | AISI 304 | AISI 316 |
| SPRING | STAINLESS STEEL |
| SEAT | EPDM |
| MFG STD | GENERALLY CONFORMING TO API 6D | API 594 |
| INSP & TEST STD | GENERALLY CONFORMING TO API 6D | API 598 |
| ENDS | FLANGE END TO ASME B16.5 RF (150#) |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) |
| SEAT : 300 Psig (21 Kg/Cm ²) | |
| SIZE RANGE | 50 MM TO 1000 MM |
| BODY | COVER | IS 210 Gr FG 200 |
| TRIMS | GUN METAL |
| MFG STD | IS 5312 PART I |
| INSP & TEST STD | IS 5312 PART I |
| ENDS | FLANGED TO IS 1538 |
| HYD-TEST PRESSURE | RATING:PN 0.6 PN 1.0 PN 1.6 |
| BODY : 0.9 Mpa 1.5 Mpa 2.4 Mpa , SEAT : 0.6 Mpa 1.0 Mpa 1.6 Mpa | |
| SIZE RANGE | 50 MM TO 1000 MM |
| BODY | COVER | ASTM A 216 Gr WCB | WC1 | WC6 | WC9 | LCB |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | BS 1868 | DIN 3356 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO DIN 2545 |
| OPERATION | AUTOMATIC |
| HYD-TEST PRESSURE | BODY : 854 Psig (60 Kg/Cm ²) |
| SEAT : 569 Psig (40 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 300 MM |
| BODY | COVER | IS 210 Gr FG 200 | 220 |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | GENERALLY CONFORMING TO BS 1868 |
| INSP & TEST STD | GENERALLY CONFORMING TO BS 6755 |
| ENDS | FLANGED TO DIN 2532 FOR PN 10 |
| FLANGED TO DIN 2533 FOR PN 16 | |
| OPERATION | AUTOMATIC |
| HYD-TEST PRESSURE | BODY : 213 Psig (15 Kg/Cm ²) |
| SEAT : 142 Psig (10 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 250 MM |
| BODY | COVER | ASTM A 216 Gr WCB | WC1 | WC6 | WC9 | LCB |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | BS 1868 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| HYD-TEST PRESSURE | BODY : 5575 Psig (392 Kg / Cm ²) |
| SEAT : 4080 Psig (287 Kg/Cm ²) | |
| SIZE RANGE | 50 MM TO 600 MM |
| BODY | COVER | ASTM A 216 Gr WCB | WC1 | WC6 | WC9 | LCB |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | BS 1868 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| HYD-TEST PRESSURE | BODY : 5575 Psig (392 Kg / Cm ²) |
| SEAT : 4080 Psig (287 Kg/Cm ²) | |
| SIZE RANGE | 50 MM TO 600 MM |
| BODY | COVER | ASTM A 216 Gr WCB | WC1 | WC6 | WC9 | LCB |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | BS 1868 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| HYD-TEST PRESSURE | 3250 Psig (228 Kg / Cm ² ) |
| 2400 Psig (168 Kg/Cm ²) | |
| SIZE RANGE | 40 MM TO 600 MM |
| BODY | COVER | ASTM A 216 Gr WCB | WC1 | WC6 | WC9 | LCB |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | BS 1868 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| HYD-TEST PRESSURE | BODY : 2175 Psig (153 Kg/Cm ²) |
| SEAT : 1600 Psig (112 Kg/Cm ²) | |
| SIZE RANGE | 25 MM TO 750 MM |
| BODY | COVER | ASTM A 216 Gr WCB | WC1 | WC6 | WC9 | LCB |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | BS 1868 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| HYD-TEST PRESSURE | BODY : 1100 Psig (77 Kg/Cm ²) |
| SEAT : 800 Psig (56 Kg/Cm ²) | |
| SIZE RANGE | 25 MM TO 1000 MM |
| BODY | COVER | ASTM A 216 Gr WCB | CF8 | CF8M | CF3 | CF3M |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | BS 1868 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| OPERATION | AUTOMATIC |
| HYD-TEST PRESSURE | BODY : 1100 Psig (77 Kg/Cm ²) |
| SEAT : 800 Psig (56 Kg/Cm ²) | |
| SIZE RANGE | 25 MM TO 300 MM |
| BODY | COVER | IS 210 Gr FG 200 | 220 |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | GENERALLY CONFORMING TO BS 1868 |
| INSP & TEST STD | GENERALLY CONFORMING TO BS 6755 |
| ENDS | FLANGED TO ASME B 16.1 FF |
| OPERATION | AUTOMATIC |
| HYD-TEST PRESSURE | BODY : 225 Psig (16 Kg/Cm ²) |
| SEAT : 165 Psig (11.5 Kg/Cm ²) | |
| SIZE RANGE | 25 MM TO 700 MM |
| BODY | COVER | ASTM A 216 Gr WCB | WC1 | WC6 | WC9 | LCB |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | BS 1868 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| OPERATION | AUTOMATIC |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) |
| SEAT : 300 Psig (21 Kg/Cm ²) | |
| SIZE RANGE | 25 MM TO 1200 MM |
| BODY | COVER | ASTM A 216 Gr WCB | CF8 | CF8M | CF3 | CF3M |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | BS 1868 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| OPERATION | AUTOMATIC |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) |
| SEAT : 300 Psig (21 Kg/Cm ²) | |
| SIZE RANGE | 25 MM TO 300 MM |
| BODY | BONNET | ASTM A 216 Gr WCB | WC1 | WC6 | WC9 | LCB |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | BS 1873 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| HYD-TEST PRESSURE | BODY : 5400 Psig (379 Kg/Cm ²) |
| SEAT : 4000 Psig (281 Kg/Cm ²) | |
| SIZE RANGE | 50 MM TO 600 MM |
| BODY | BONNET | ASTM A 216 Gr WCB | WC1 | WC6 | WC9 | LCB |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | BS 1873 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| HYD-TEST PRESSURE | BODY : 3250 Psig (228 Kg/Cm ²) |
| SEAT : 2400 Psig (168 Kg/Cm ²) | |
| SIZE RANGE | 40 MM TO 600 MM |
| BODY | BONNET | ASTM A 351 Gr CF8 | CF8M | CF3 | CF3M |
| TRIMS | 18 Cr 8 Ni | 18 Cr 10 Ni -2 MO | CF3M |
| MFG STD | BS 1873 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| HYD-TEST PRESSURE | BODY : 2175 Psig (153 Kg/Cm ²) |
| SEAT : 1600 Psig (112 Kg/Cm ²) | |
| SIZE RANGE | 25 MM TO 750 MM |
| BODY | BONNET | ASTM A 216 Gr WCB | WC1 | WC6 | WC9 | LCB |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | BS 1873 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| HYD-TEST PRESSURE | BODY : 1100 Psig (77 Kg/Cm ²) |
| SEAT : 800 Psig (56 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 1000 MM |
| BODY | BONNET | ASTM A 216 Gr WCB | CF8 | CF8M | CF3 | CF3M |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | BS 1873 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| HYD-TEST PRESSURE | BODY : 1100 Psig (77 Kg/Cm ²) |
| SEAT : 800 Psig (56 Kg/Cm ²) | |
| SIZE RANGE | 25 MM TO 300 MM |
| BODY | BONNET | ASTM A 216 Gr WCB | WC1 | WC6 | WC9 | LCB |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | BS 1873 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) |
| SEAT : 300 Psig (21 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 1200 MM |
| BODY | BONNET | ASTM A 216 Gr WCB | CF8 | CF8M | CF3 | CF3M |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | BS 1873 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) |
| SEAT : 300 Psig (21 Kg/Cm ²) | |
| SIZE RANGE | 25 MM TO 300 MM |
| BODY | BONNET | IS 210 Gr FG 200 | WCB |
| TRIMS | GUN METAL | BRONZE | SS 410 |
| MFG STD | 50 MM TO 300 MM -IS 780 PN 1.0 | 1.6 300MM -IS 2906 RATING PN 0.4 | 0.6 | 1.0 | 1.6 |
| INSP & TEST STD | 50 MM TO 300 MM -IS 780 RATING PN 1.0 | 1.6 300MM -IS 2906 PN 0.4 | 0.6 | 1.0 | 1.6 |
| RATING | PN 0.4 PN 0.6 PN 1.0 PN 1.6 |
| ENDS | FLANGED TO IS 1538 | ASME B 16.1 (125#) |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| HYD-TEST PRESSURE | BODY : 0.6Mpa 0.9Mpa 1.5Mpa 2.4Mpa |
| SEAT : 0.4Mpa 0.6Mpa 1.0Mpa 1.6Mpa | |
| SIZE RANGE | 50 MM TO 1800 MM |
| BODY | BONNET | IS 210 Gr FG 200 | WCB |
| TRIMS | SS 410 | GUN METAL |
| MFG STD | IS 14846 |
| INSP & TEST STD | IS 14846 |
| RATING | PN 0.4 | PN 0.6 | PN 1.0 |
| ENDS | FLANGED TO IS 1538 |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| HYD-TEST PRESSURE | BODY : 0.6Mpa 0.9Mpa 1.5Mpa |
| SEAT : 0.4Mpa 0.6Mpa 1.0Mpa | |
| SIZE RANGE | 50 MM TO 1200 MM |
| BODY | ASTM A 216 Gr WCB | CF8 | CF8M | CF3 | CF3M |
| SEAT | NITRILE |
| INSP & TEST STD | MSS SP – 81 |
| KNIFE PLATE | ANSI S S 304 |
| LEAKAGE CLASS | CLASS – VI (Tight shut off) |
| ENDS | LUGGED TO ASME B 16.5 RF |
| OPERATION | MANUAL | CHAIN WHEEL OPERATED | CYLINDER OPERATED |
| HYD-TEST PRESSURE | BODY : 71 Psig (5 Kg/Cm ²) |
| SEAT : 40 Psig (2.8 Kg/Cm ²) | |
| SIZE RANGE | 50 MM TO 300 MM |
| BODY | IS 210 Gr. FG 200 | WCB | WC1 | WC6 | WC9 | LCB | CF8 | CF8M | CF3 | CF3M |
| SEAT | NITRILE | METAL TO METAL |
| INSP & TEST STD | MSS SP -81 |
| KNIFE PLATE | ASTM A 351 Gr CF8 | CF8M | CI | WCB | CF3 | CF3M |
| LEAKAGE CLASS | CLASS – IV |
| ENDS | FLANGED | LUGGED TO ASME B16.5 RF (150#) |
| OPERATION | MANUAL | CHAIN WHEEL OPERATED | CYLINDER OPERATED |
| HYD-TEST PRESSURE | BODY : 156 Psig (11 Kg/Cm ²) |
| SEAT : 40 Psig (2.8 Kg/Cm ²) | |
| SIZE RANGE | 40 MM TO 750 MM |
| BODY | BONNET | IS 210 Gr FG 200 | WCB |
| TRIMS | SS 410 | GUN METAL |
| MFG STD | IS 14846 |
| INSP & TEST STD | IS 14846 |
| RATING | PN 0.4 | PN 0.6 | PN 1.0 |
| ENDS | FLANGED TO IS 1538 |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| HYD-TEST PRESSURE | BODY : 0.6Mpa 0.9Mpa 1.5Mpa |
| SEAT : 0.4Mpa 0.6Mpa 1.0Mpa | |
| SIZE RANGE | 50 MM TO 1200 MM |
| BODY | BONNET | ASTM A 216 Gr WCB | CF8 | CF8M | CF3 | CF3M |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | BS 1873 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) |
| SEAT : 300 Psig (21 Kg/Cm ²) | |
| SIZE RANGE | 25 MM TO 300 MM |
| BODY | BONNET | ASTM A 216 Gr WCB | CF8 | CF8M | CF3 | CF3M |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | BS 1873 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| HYD-TEST PRESSURE | BODY : 1100 Psig (77 Kg/Cm ²) |
| SEAT : 800 Psig (56 Kg/Cm ²) | |
| SIZE RANGE | 25 MM TO 300 MM |
| BODY | BONNET | ASTM A 351 Gr CF8 | CF8M | CF3 | CF3M |
| TRIMS | 18 Cr 8 Ni | 18 Cr 10 Ni -2 MO | CF3M OR AISI 316L |
| MFG STD | BS 1873 | DIN 3356 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO DIN 2545 |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| HYD-TEST PRESSURE | BODY : 854 Psig (60 Kg/Cm ²) |
| SEAT : 569 Psig (40 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 400 MM |
| BODY | BONNET | IS 210 Gr FG 200 | 220 |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | GENERALLY CONFORMING TO BS 1873 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO DIN 2533 2532 FOR PN 10 |
| FLANGED TO DIN 2533 FOR PN 16 | |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| HYD-TEST PRESSURE | BODY : 213 Psig (15 Kg/Cm ²) |
| SEAT : 142 Psig (10 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 250 MM |
| BODY | BONNET | ASTM A 216 Gr WCB | CF8 | CF8M | CF3 | CF3M |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | BS 1873 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF (300#) |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| HYD-TEST PRESSURE | BODY : 854 Psig (60 Kg/Cm ²) |
| SEAT : 569 Psig (40 Kg/Cm ²) | |
| SIZE RANGE | 15 MM TO 150 MM |
| BODY | BONNET | ASTM A 216 Gr WCB | WC1 | WC6 | WC9 | LCB |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | API 600 |
| INSP & TEST STD | API 598 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| HYD-TEST PRESSURE | BODY : 9275 Psig (652 Kg/Cm ²) |
| SEAT : 6790 Psig (477 Kg/Cm ²) | |
| SIZE RANGE | 50 MM TO 600MM |
| BODY | BONNET | ASTM A 216 Gr WCB | WC1 | WC6 | WC9 | LCB |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | BS 1873 |
| INSP & TEST STD | BS 6755 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| HYD-TEST PRESSURE | BODY : 9275 Psig (652 Kg/Cm ²) |
| SEAT : 6790 Psig (281 Kg/Cm ²) | |
| SIZE RANGE | 50 MM TO 600 MM |
| BODY | BONNET | ASTM A 216 Gr WCB | WC1 | WC6 | WC9 | LCB |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | API 600 |
| INSP & TEST STD | API 598 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| HYD-TEST PRESSURE | BODY : 9275 Psig (652 Kg/Cm ²) |
| SEAT : 6790 Psig (477 Kg/Cm ²) | |
| SIZE RANGE | 50 MM TO 600MM |
| BODY | BONNET | ASTM A 216 Gr WCB | WC1 | WC6 | WC9 | LCB |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | API 600 |
| INSP & TEST STD | API 598 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| HYD-TEST PRESSURE | BODY : 5575 Psig (392 Kg/Cm ²) |
| SEAT : 4080 Psig (287 Kg/Cm ²) | |
| SIZE RANGE | 50 MM TO 600 MM |
‘
| BODY | BONNET | ASTM A 216 Gr WCB | WC1 | WC6 | WC9 | LCB |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | API 600 |
| INSP & TEST STD | API 598 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| HYD-TEST PRESSURE | BODY : 3250 Psig (228 Kg/Cm ²) |
| SEAT : 2400 Psig (168 Kg/Cm ²) | |
| SIZE RANGE | 50 MM TO 600 MM |
| BODY | BONNET | ASTM A 216 Gr WCB | WC1 | WC6 | WC9 | LCB ASTM A 351 Gr CF8 | CF8M | CF3 | CF3M |
| TRIMS | 13Cr | 18 Cr 8Ni 18 Cr 8 Ni | 18 Cr 10 Ni – 2MO | CF3M OR AISI 316 L |
| MFG STD | API 600 |
| INSP & TEST STD | API 598 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| HYD-TEST PRESSURE | BODY : 2175 Psig (153 Kg/Cm ²) |
| SEAT : 1630 Psig (115 Kg/Cm ²) | |
| SIZE RANGE | 25 MM TO 750 MM |
| BODY | BONNET | ASTM A 216 Gr WCB | WC1 | WC6 | WC9 | LCB |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | API 600 |
| INSP & TEST STD | API 598 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| HYD-TEST PRESSURE | BODY : 1100 Psig (77 Kg/Cm ²) |
| SEAT : 800 Psig (56 Kg/Cm ²) | |
| SIZE RANGE | 25 MM TO 1000 MM |
| BODY | BONNET | ASTM A 216 Gr WCB | CF8 | CF8M | CF3 | CF3M |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | API 600 |
| INSP & TEST STD | API 598 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| HYD-TEST PRESSURE | BODY : 1100 Psig (77 Kg/Cm ²) |
| SEAT : 800 Psig (56 Kg/Cm ²) | |
| SIZE RANGE | 25 MM TO 300 MM |
| BODY | BONNET | ASTM A 216 Gr WCB | WC1 | WC6 | WC9 | LCB |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | API 600 |
| INSP & TEST STD | API 598 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) |
| SEAT : 300 Psig (21 Kg/Cm ²) | |
| SIZE RANGE | 25 MM TO 1200 MM |
| BODY | BONNET | IS 210 Gr FG 200 | 220 |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | GENERALLY CONFORMING TO API 600 | BS 5150 |
| INSP & TEST STD | GENERALLY CONFORMING TO API 598 | BS 6755 |
| ENDS | FLANGED TO ASME B 16.1 FF |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| HYD-TEST PRESSURE | BODY : 225 Psig (16 Kg/Cm ²) |
| SEAT : 165 Psig (11.5 Kg/Cm ²) | |
| SIZE RANGE | 25 MM TO 1200 MM |
| BODY | BONNET | ASTM A 216 Gr WCB | CF8 | CF8M | CF3 | CF3M |
| TRIMS | 13 Cr | 18 Cr 8 Ni |
| MFG STD | API 600 |
| INSP & TEST STD | API 598 |
| ENDS | FLANGED TO ASME B 16.5 RF |
| OPERATION | MANUAL | GEAR | ELECTRICAL ACTUATED |
| HYD-TEST PRESSURE | BODY : 425 Psig (30 Kg/Cm ²) |
| SEAT : 300 Psig (21 Kg/Cm ²) | |
| SIZE RANGE | 25 MM TO 300 MM |
